One socket for a 100-Gigabit CFP transceiver.
Supported CFP transceivers:
•
100GBASE-LR4 (model number: SRX-CFP-100G-LR4)
•
100GBASE-SR10 (model number: SRX-CFP-100G-SR10)
Cables and connectors
Either slot in SRX5K-MPCSupported slots
Approximately 1.6 lb (0.7 kg)Weight
OK/FAIL LED, one bicolor:
•
Green–The MIC is operating normally.
•
Red–The MIC has failed and is not operating normally.
•
Off–The MIC is powered down.
LINK LED, single color:
•
Green–The link is active.
•
Off–No link.
LEDs
The serial number label is yellow and located as shown in Figure 27 on page 52.
Figure 27: SRX-MIC-1X100G-CFP Serial Number Label
g007692
Serial number
ID label
Serial number location
52
