The serial number label is yellow and typically located as shown in
Figure 29 on page 54.
Figure 29: SRX-MIC-2X40G-QSFP Serial Number Label
g007693
Serial number
ID label
Serial number location
SRX5K-MPC3-40G10G Specifications
The SRX5K-MPC3-40G10G (IOC3) is an interface card that provides 10 Gigabit Ethernet and 40 Gigabit
Ethernet interfaces, with a Packet Forwarding Engine that provides a 240 Gbps line rate. This interface
card is supported on SRX5400, SRX5600, and SRX5800 Services Gateways. See Figure 30 on page 55.
NOTE: These cards do not support plug-in Modular Interface Cards (MICs).
All ports on the interface card have dual-color LEDs for reporting link status.
The interface card also supports hot-pluggable optical modules.
54
