Slot for Routing Engine
•
AUX–Connects the Routing Engine to a laptop, a modem, or another auxiliary device
through a cable with an RJ-45 connector.
•
CONSOLE–Connects the Routing Engine to a system console through a cable with an
RJ-45 connector.
•
MGMT–Connects the Routing Engine through an Ethernet connection to a management
LAN (or any other device that plugs into an Ethernet connection) for out-of-band
management.
Cables and connectors
RESET button–Reboots the Routing Engine when pressed.
Controls
Front panel slot in an SCB installed in:
•
SRX5400: Bottom slot 0
•
SRX5600: Bottom slots 0 or 1
•
SRX5800: Center slots 0 or 1
NOTE: The services gateway host subsystem Routing Engine must be installed in the
SCB in slot 0. A Routing Engine installed in an SCB in slot 1 only enables dual control links
in chassis cluster configurations.
NOTE: In the SRX5600 or SRX5800 Services Gateways chassis cluster configurations,
dual control links functionality is not supported if you mix SRX5K-RE-1800X4 and
SRX5K-RE3-128G Routing Engines. To support dual control links you have to install two
SRX5K-RE3-128Gs.
Supported slots
110 W
Power requirement
2.69 lb (1.22 kg)
Weight
