3-4(No.YA362)
EXPLODED VIEW PARTS LIST -1
Ref.No. Part No. Part Name Description Local
101 LC12199-001B JACK COVER (x2)
102 LC41424-002A HDMI WARNING
103 LC42090-002A-H LICENSE LABEL
104 LC41999-002A CAUTION LABEL
105 LC42376-001A-C STAND BASE UNIT
106 LC42292-001A-C SUPPORT UNIT Inc.106A
106A T0106-01 STAND COVER
107 QYSPSPD5014MA SCREW M5 x 14mm(x4)
108 QYSPSPD3020ZA SCREW M3 x 20mm
109 LC12359-003B REAR COVER Inc.109A-109C
109A LC33167-003A OPERATION SHEET
109B LC33168-003B OPERATION SHEET
109C LC33214-001B SD CARD COVER
110 QYSBSFG4016MA TAP SCREW M4 x 16mm(x10)
111 QYSBSF3010MA TAP SCREW M3 x 10mm(x3)
112 QYSPSPD3006MA SCREW M3 x 6mm(x2)
113 QMPK300-170-JC POWER CORD(EU) 1.7m BLACK LT-Z37DX5
113 QMPG110-170-JC POWER CORD(AST) 1.7m BLACK LT-Z37DX5/A
113 QMPN260-170-JC POWER CORD(EK) 1.7m BLACK LT-Z37DX5/S
114 QQR0491-001 FERRITE CORE
115 LC33103-001A POWER CORD HOLDER
116 QQR0490-001 NOISE FILTER LT-Z37DX5/A,LT-Z37DX5/S
117 LC21597-006B-HK TUNER BASE
118 QYSPSP3008MA SCREW M3 x 8mm
119 QYSPSPD3006MA SCREW M3 x 6mm(x3)
120 LC32760-001A-HK SERVICE COVER
121 QYSBSF3010MA TAP SCREW M3 x 10mm
122 WJW0035-001A-E DIGITAL(LVDS) CABLE
123 QUQ105-5004AA-E FFC WIRE 50pin 4cm
124 QUQ105-3004AA-E FFC WIRE 30pin 4cm
125 QUQ105-5013AE-E FFC WIRE 50pin 13cm
126 QUQ105-5013AE-E FFC WIRE 50pin 13cm
127 QUQK12-2106CH-E FFC WIRE 21pin 6cm
128 LC21596-005A-HK TERMINAL BASE
129 QYSBSF3010MA TAP SCREW M3 x 10mm(x7)
130 LC33196-004B CONTROL ASSY
131 QNB0036-001 HEX SCREW (x2)
132 QQR0491-001 FERRITE CORE LT-Z37DX5/A,LT-Z37DX5/S
133 QQR0490-001 NOISE FILTER
201 LCA90464-19A REGULATOR PWB
202 LCA90463-21A MAIN POWER PWB
203 LCA10557-85A DIGITAL SIGNAL PWB LT-Z37DX5
203 LCA10557-87A DIGITAL SIGNAL PWB LT-Z37DX5/A
203 LCA10557-86A DIGITAL SIGNAL PWB LT-Z37DX5/S
204 LCA10652-01A PANEL I/F PWB
205 LCA90581-01A RECEIVER PWB
206 LCA90537-03A ANALOG SIGNAL PWB
207 LCA90469-04A FRONT CONTROL PWB
