JVC LT-Z37DX5 Service Manual

3-8(No.YA362)
PRINTED WIRING BOARD PARTS LIST [LT-Z37DX5]
ANALOG SIGNAL P.W. BOARD ASS'Y
(LCA90537-03A) (SFL-1133A)
 Ref No. Part No. Part Name Description Local
IC201 TA1370FG-X IC
IC301 AN15852A IC
IC501 CXA2069Q IC
IC502 MM1510XN-X IC
IC503 MM1510XN-X IC
IC504 MM1510XN-X IC
IC711 CXA1875AM-X IC
IC801 TB1274BFG IC
IC802 TC90A69AF-X IC
IC902 TA48M033F-X IC
IC903 BA90BC0FP-X IC
IC6001 NJM2777M-X IC
IC6201 PQ20WZ11-X IC
IC6521 NJW1164M-W IC
IC6551 RC4558D-X IC
IC6552 RC4558D-X IC
IC6621 LM393DR-X IC
IC6661 TDA8925ST/N1 IC
Q301 2SC3837K/NP/-X TRANSISTOR
Q302 2SC3837K/NP/-X TRANSISTOR
Q303 2SC3837K/NP/-X TRANSISTOR
Q307 2SA1530A/QR/-X TRANSISTOR
Q402 SSM3K17FU-X MOS FET
Q403 SSM3K17FU-X MOS FET
Q404 SSM3K17FU-X MOS FET
Q405 SSM3K17FU-X MOS FET
Q507 2SA1530A/QR/-X TRANSISTOR
Q508 2SA1530A/QR/-X TRANSISTOR
Q509 2SA1530A/QR/-X TRANSISTOR
Q801 2SA1530A/QR/-X TRANSISTOR
Q802 2SA1530A/QR/-X TRANSISTOR
Q851 2SA1530A/QR/-X TRANSISTOR
Q853 2SC3928A/QR/-X TRANSISTOR
Q854 2SC3928A/QR/-X TRANSISTOR
Q855 2SA1530A/QR/-X TRANSISTOR
Q858 2SC3928A/QR/-X TRANSISTOR
Q859 2SA1530A/QR/-X TRANSISTOR
Q862 2SC3928A/QR/-X TRANSISTOR
Q863 2SC3928A/QR/-X TRANSISTOR
Q902 2SC3074/OY/-X TRANSISTOR
Q903 2SC3928A/QR/-X TRANSISTOR
Q2051 UN2226-X DIGI TRANSISTOR
Q2052 UN2226-X DIGI TRANSISTOR
Q2055 UN2110-X DIGI TRANSISTOR
Q6301 2SC3928A/QR/-X TRANSISTOR
Q6302 2SC3928A/QR/-X TRANSISTOR
Q6421 2SC3928A/QR/-X TRANSISTOR
Q6431 2SA1530A/QR/-X TRANSISTOR
Q6521 2SC3928A/QR/-X TRANSISTOR
Q6522 2SC3928A/QR/-X TRANSISTOR
Q6523 2SA1530A/QR/-X TRANSISTOR
Q6531 2SC3928A/QR/-X TRANSISTOR
Q6532 2SC3928A/QR/-X TRANSISTOR
Q6533 2SC3928A/QR/-X TRANSISTOR
Q6534 2SA1530A/QR/-X TRANSISTOR
Q6538 2SC3928A/QR/-X TRANSISTOR
Q6539 2SC3928A/QR/-X TRANSISTOR
Q6661 UN2112-X DIGI TRANSISTOR
Q6662 2SC3928A/QR/-X TRANSISTOR
Q6663 UN2212-X DIGI TRANSISTOR
Q6673 2SA1530A/QR/-X TRANSISTOR
D901 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
D902 1SS355-X SI DIODE
D903 PTZ11B-X Z DIODE
D904 PTZ6.8B-X Z DIODE
D905 MA8030/H/-X Z DIODE
D2001 UDZS10B-X Z DIODE
D2002 UDZS10B-X Z DIODE
D2003 UDZS10B-X Z DIODE
D2004 UDZS10B-X Z DIODE
D2005 UDZS10B-X Z DIODE
D2006 UDZS10B-X Z DIODE
D2007 UDZS10B-X Z DIODE
D2008 UDZS10B-X Z DIODE
D2009 UDZS10B-X Z DIODE
D2010 UDZS10B-X Z DIODE
D2011 UDZS10B-X Z DIODE
D2012 UDZS10B-X Z DIODE
D2013 UDZS10B-X Z DIODE
D2014 UDZS10B-X Z DIODE
D2015 UDZS10B-X Z DIODE
D2016 UDZS10B-X Z DIODE
D2017 UDZS10B-X Z DIODE
D2053 UDZS10B-X Z DIODE
D2054 UDZS10B-X Z DIODE
D2201 UDZS10B-X Z DIODE
D2202 UDZS10B-X Z DIODE
D2203 UDZS10B-X Z DIODE
D2204 UDZS10B-X Z DIODE
D2205 UDZS10B-X Z DIODE
D2206 UDZS10B-X Z DIODE
D2207 UDZS10B-X Z DIODE
D6001 1SS355-X SI DIODE
D6002 1SS355-X SI DIODE
D6201 1SS355-X SI DIODE
D6431 1SS355-X SI DIODE
D6432 1SS355-X SI DIODE
D6433 1SS355-X SI DIODE
D6501 1SS355-X SI DIODE
D6502 1SS355-X SI DIODE
D6503 1SS355-X SI DIODE
D6504 1SS355-X SI DIODE
D6601 UDZS6.2B-X Z DIODE
D6663 UDZS3.3B-X Z DIODE
D6664 1SS355-X SI DIODE
D6671 UDZS20B-X Z DIODE
D6672 UDZS20B-X Z DIODE
D6673 UDZS20B-X Z DIODE
D6674 UDZS20B-X Z DIODE
D6681 1SS355-X SI DIODE
D6682 1SS355-X SI DIODE
D6683 1SS355-X SI DIODE
DB201 UDZS3.3B-X Z DIODE
C201 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C202 NEHL1HM-225X E CAPACITOR 2.2uF 50V M
C203 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C204 NELA1AM-157X E CAPACITOR 150uF 10V M
C205 NEHL1HM-105X E CAPACITOR 1uF 50V M
C206 NCB21CK-105X C CAPACITOR 1uF 16V K
C207 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C301 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C302 NEHL1CM-476X E CAPACITOR 47uF 16V M
C303 NRSA02J-221X MG RESISTOR 220 Ω 1/10W J
C304 NRSA02J-221X MG RESISTOR 220 Ω 1/10W J
C305 NRSA02J-221X MG RESISTOR 220 Ω 1/10W J
C306 NDC31HJ-560X C CAPACITOR 56pF 50V J
C307 NDC31HJ-560X C CAPACITOR 56pF 50V J
C308 NDC31HJ-560X C CAPACITOR 56pF 50V J
C313 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C314 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C315 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C316 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C317 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C318 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C319 NEHL1CM-476X E CAPACITOR 47uF 16V M
C320 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C321 NEHL1CM-106X E CAPACITOR 10uF 16V M
C322 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C323 NBZ0010-396X SP E CAPACITOR 39uF 16V M
C324 NCB21CK-105X C CAPACITOR 1uF 16V K
C325 NCB21CK-105X C CAPACITOR 1uF 16V K
C326 NCB21CK-105X C CAPACITOR 1uF 16V K
C327 NCB21CK-105X C CAPACITOR 1uF 16V K
C328 NCB21CK-105X C CAPACITOR 1uF 16V K
C329 NCB21CK-105X C CAPACITOR 1uF 16V K
C330 NCB21CK-105X C CAPACITOR 1uF 16V K
C341 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C342 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C343 NCB21CK-105X C CAPACITOR 1uF 16V K
C346 NCB21CK-105X C CAPACITOR 1uF 16V K
C349 NCB11AK-106X C CAPACITOR 10uF 10V K
C372 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C382 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C392 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C501 NEHL1CM-476X E CAPACITOR 47uF 16V M
C502 NEHL1CM-476X E CAPACITOR 47uF 16V M
C503 NENA1EM-106X BP E CAPACITOR 10uF 25V M
C505 NENA1EM-106X BP E CAPACITOR 10uF 25V M
C506 NDC31HJ-270X C CAPACITOR 27pF 50V J
C515 NCB21CK-105X C CAPACITOR 1uF 16V K
C516 NEHL1CM-106X E CAPACITOR 10uF 16V M
C518 NEHL1AM-107X E CAPACITOR 100uF 10V M
C519 NEHL1CM-106X E CAPACITOR 10uF 16V M
C520 NCB21CK-105X C CAPACITOR 1uF 16V K
C521 NEHL1CM-106X E CAPACITOR 10uF 16V M
C522 NEHL1AM-107X E CAPACITOR 100uF 10V M
C523 NEHL1CM-106X E CAPACITOR 10uF 16V M
C524 NCB21CK-105X C CAPACITOR 1uF 16V K
 Ref No. Part No. Part Name Description Local
