JVC LT-Z37DX5 Service Manual

3-12(No.YA362)
RECEIVER P.W. BOARD ASS'Y
(LCA90581-01A) (SFL-4133A)
L866 NQL914K-220X COIL 22uH K
L867 NQL914K-220X COIL 22uH K
L902 NQL52EM-220X COIL 22uH M
L903 NQL52EM-220X COIL 22uH M
L904 NQL52EM-220X COIL 22uH M
L6661 QQL28AK-560 COIL 56uH K
L6662 QQL28AK-560 COIL 56uH K
CN000H QGF1201C2-21 CONNECTOR FFC/FPC (1-21)
CN0011 QGF0508F1-50X CONNECTOR FFC/FPC (1-50)
CN0012 QGF0508F1-50X CONNECTOR FFC/FPC (1-50)
J2001 QNZ0726-001 AV JACK INPUT-1(S/V/L/R)
J2002 QNZ0693-001 D CONNECTOR INPUT-1(COMPONENT)
J2003 QNZ0726-001 AV JACK INPUT-2(S/V/L/R)
J2004 QNN0651-001 PIN JACK INPUT-3(V/L/R)
J2006 QNN0650-001 PIN JACK INPUT-3(COMPONENT)
J2007 QNZ0561-001 D CONNECTOR PC IN(RGB)
J2008 QNZ0726-001 AV JACK V/A OUT(V/L/R)
J2009 QNN0652-001 PIN JACK DIGITAL IN AUDIO
K6601 NQR0499-002X FERRITE BEADS
K6602 NQR0499-002X FERRITE BEADS
K6661 NQR0499-002X FERRITE BEADS
K6662 NQR0499-002X FERRITE BEADS
K6663 NQR0499-002X FERRITE BEADS
K6664 NQR0499-002X FERRITE BEADS
 TH6661 NAD0035-471X P THERMISTOR 470 Ω
X201 QAX0687-001 C RESONATOR 503.50kHz
X801 NAX0621-001X CRYSTAL 16.200MHz
 Ref No. Part No. Part Name Description Local
IC3101 M62320FP-X IC
IC3106 TPS852-W PHOTO CONDUCTOR
IC3501 MSP3415GQGB8V3M IC
IC3504 BA80BC0FP-X IC
IC3601 AN5285K IC
IC3651 HA17558AF-X IC
IC4301 RC4558D-X IC
IC4401 TL52055PW-X IC
IC4402 TL52055PW-X IC
IC4501 TC7WH126FU-X IC
IC4502 TC7WH240FU-X IC
Q3001 2SC3928A/QR/-X TRANSISTOR
Q3502 2SC3928A/QR/-X TRANSISTOR
Q3503 UN2213-X DIGI TRANSISTOR
D4501 MA8033-X Z DIODE
C3003 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C3004 NEHL1AM-107X E CAPACITOR 100uF 10V M
C3007 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C3008 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C3009 NEHL1HM-106X E CAPACITOR 10uF 50V M
C3010 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C3011 NEHL1HM-106X E CAPACITOR 10uF 50V M
C3012 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C3101 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z
C3161 NCB11AK-106X C CAPACITOR 10uF 10V K
C3162 NCB11AK-106X C CAPACITOR 10uF 10V K
C3163 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C3501 NCB11AK-106X C CAPACITOR 10uF 10V K
C3502 NCB31CK-273X C CAPACITOR 0.027uF 16V K
C3503 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C3504 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C3505 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
C3511 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C3512 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C3513 NDC31HJ-2R0X C CAPACITOR 2pF 50V J
C3514 NDC31HJ-2R0X C CAPACITOR 2pF 50V J
C3515 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C3516 NEHL1AM-107X E CAPACITOR 100uF 10V M
C3517 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C3518 NCB31HK-222X C CAPACITOR 2200pF 50V K
C3519 NCB31CK-273X C CAPACITOR 0.027uF 16V K
C3520 NCB31CK-273X C CAPACITOR 0.027uF 16V K
C3523 NDC31HJ-102X C CAPACITOR 1000pF 50V J
C3524 NDC31HJ-102X C CAPACITOR 1000pF 50V J
C3525 NEHL1CM-106X E CAPACITOR 10uF 16V M
C3526 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C3527 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C3528 NEHL1AM-107X E CAPACITOR 100uF 10V M
C3529 NEHL1CM-106X E CAPACITOR 10uF 16V M
C3530 NCB11AK-106X C CAPACITOR 10uF 10V K
 Ref No. Part No. Part Name Description Local
C3531 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C3532 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C3533 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C3534 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C3535 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C3536 NCB11AK-106X C CAPACITOR 10uF 10V K
C3537 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C3544 NCB31AK-105X C CAPACITOR 1uF 10V K
C3545 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C3546 NCB31AK-105X C CAPACITOR 1uF 10V K
C3547 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C3601 NEHL1EM-475X E CAPACITOR 4.7uF 25V M
C3602 NCB31AK-105X C CAPACITOR 1uF 10V K
C3603 NEHL1AM-107X E CAPACITOR 100uF 10V M
C3604 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C3605 NEHL1CM-106X E CAPACITOR 10uF 16V M
C3607 NCB31AK-105X C CAPACITOR 1uF 10V K
C3608 NEHL1CM-106X E CAPACITOR 10uF 16V M
C3609 NCB31AK-105X C CAPACITOR 1uF 10V K
C3610 NCB31AK-105X C CAPACITOR 1uF 10V K
C3611 NCB31AK-105X C CAPACITOR 1uF 10V K
C3612 NCB31AK-105X C CAPACITOR 1uF 10V K
C3651 NCB31AK-105X C CAPACITOR 1uF 10V K
C3652 NCB31AK-105X C CAPACITOR 1uF 10V K
C3653 NEHL1CM-476X E CAPACITOR 47uF 16V M
C3654 NEHL1CM-476X E CAPACITOR 47uF 16V M
C4303 NEHL1CM-106X E CAPACITOR 10uF 16V M
C4304 NEHL1CM-106X E CAPACITOR 10uF 16V M
C4305 NEHL1CM-476X E CAPACITOR 47uF 16V M
C4306 NEHL1CM-476X E CAPACITOR 47uF 16V M
C4401 NCB11AK-106X C CAPACITOR 10uF 10V K
C4402 NCB11AK-106X C CAPACITOR 10uF 10V K
C4405 NCB11AK-106X C CAPACITOR 10uF 10V K
C4406 NCB11AK-106X C CAPACITOR 10uF 10V K
C4407 NCB11AK-106X C CAPACITOR 10uF 10V K
C4408 NCB11AK-106X C CAPACITOR 10uF 10V K
C4409 NCB11AK-106X C CAPACITOR 10uF 10V K
C4410 NCB11AK-106X C CAPACITOR 10uF 10V K
C4414 NCB11AK-106X C CAPACITOR 10uF 10V K
C4415 NCB11AK-106X C CAPACITOR 10uF 10V K
C4416 NCB11AK-106X C CAPACITOR 10uF 10V K
C4417 NCB11AK-106X C CAPACITOR 10uF 10V K
C4418 NCB11AK-106X C CAPACITOR 10uF 10V K
C4419 NCB21AK-105X C CAPACITOR 1uF 10V K
C4420 NCB21AK-105X C CAPACITOR 1uF 10V K
C4421 NDC31HJ-101X C CAPACITOR 100pF 50V J
C4422 NCB21CK-105X C CAPACITOR 1uF 16V K
C4423 NCB21CK-105X C CAPACITOR 1uF 16V K
C4501 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
R3004 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3005 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3006 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3007 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3008 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R3009 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R3010 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3011 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3014 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R3015 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R3016 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R3028 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R3029 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R3101 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R3102 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R3103 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R3104 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R3111 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R3112 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R3191 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R3501 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R3502 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R3508 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3511 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R3512 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R3513 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R3514 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R3515 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R3516 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3517 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R3522 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R3523 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R3546 NRSA63J-152X MG RESISTOR 1.5k
Ω 1/16W J
R3547 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R3601 NRSA63J-225X MG RESISTOR 2.2M
Ω 1/16W J
R3602 NRSA63J-392X MG RESISTOR 3.9k
Ω 1/16W J
R3605 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R3606 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R3607 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R3608 NRSA63J-392X MG RESISTOR 3.9k
Ω 1/16W J
 Ref No. Part No. Part Name Description Local
