JVC LT-Z37DX5 - Panel I;F P.w. Board Assy (Lca10652-01 A) (Sfl-0 H001 A)

(No.YA362)3-31
PANEL I/F P.W. BOARD ASS'Y
(LCA10652-01A) (SFL-0H001A)
REFER TO PARTS LIST IN PAGE 3-23 FOR THIS P.W. BOARD.
L1303 NQL092K-1R0X P COIL 1uH K
L1304 NQL093K-R10X P COIL 0.1uH K
L1401 NQL092K-3R3X P COIL 3.3uH K
L1403 NQL092K-1R0X P COIL 1uH K
L1404 NQL093K-R10X P COIL 0.1uH K
L1501 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
L1533 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
L1534 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
L3005 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
L3006 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
L3008 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
L3009 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
L3010 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
L3011 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
L3012 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
L3013 NQL093K-R10X P COIL 0.1uH K
L3014 NQL093K-R10X P COIL 0.1uH K
L3015 NQL093K-R10X P COIL 0.1uH K
L3501 NQR0413-003X FERRITE BEADS
L4001 NQR0413-003X FERRITE BEADS
L4002 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
L4003 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
L6501 NQR0351-001X FERRITE BEADS
L6502 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
L6508 NRZ0034-0R0W NET RESISTOR 0
Ω 1/32W J x4
L6509 NRZ0034-0R0W NET RESISTOR 0 Ω 1/32W J x4
L6510 NRZ0034-0R0W NET RESISTOR 0
Ω 1/32W J x4
L7001 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
L7002 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
L7003 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
L7004 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
L7005 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
L7006 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
L7510 NQL092K-4R7X P COIL 4.7uH K
L7512 NQR0489-002X FERRITE BEADS
L7513 NQR0489-002X FERRITE BEADS
L9001 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
L9002 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
L9201 NQL71EM-150X COIL 15uH M
CN001 QGF0508F1-50X CONNECTOR FFC/FPC (1-50)
CN002 QGF0508F1-30X CONNECTOR FFC/FPC (1-30)
J001 NNZ0117-001 HDMI CONNECTOR DIGITAL IN
K1001 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K1002 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K1003 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K1004 NQR0489-002X FERRITE BEADS
K1005 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K3003 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K3006 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K3009 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K3191 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K7502 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K7503 NQR0389-003X FERRITE BEADS
K9001 NQR0413-003X FERRITE BEADS
K9002 NQR0413-003X FERRITE BEADS
LC0102 NQR0483-005X EMI FILTER 100uF 25V Z
LC0519 NQR0416-001X EMI FILTER 240pF 16V M
LC0522 NQR0470-007X EMI FILTER
2200pF 50V +50%-20%
LC0524 NQR0483-005X EMI FILTER 100uF 25V Z
LC0527 NQR0483-006X EMI FILTER
LC6501 NQR0479-001X EMI FILTER
LC7004 NQR0483-003X EMI FILTER
LC7501 NQR0483-006X EMI FILTER
LC7502 NQR0483-006X EMI FILTER
SL7001 NAX0613-001X C RESONATOR
TP9001 LC42312-001A EARTH TERMINAL
TP9002 LC42312-001A EARTH TERMINAL
TP9003 LC42312-001A EARTH TERMINAL
X1001 NAX0642-001X CRYSTAL
X3001 NAX0635-001X CXO
X3003 NAX0668-001X CXO
X4001 NAX0669-001X C RESONATOR
X7501 NAX0618-001X CRYSTAL
 Ref No. Part No. Part Name Description Local
