JVC LT-Z37DX5 Service Manual

(No.YA362)3-15
MAIN POWER P.W. BOARD ASS'Y
(LCA90463-21A) (SFL-9039A)
R2018 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R2019 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R2020 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R2021 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R2022 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R2025 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R2026 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R2027 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R2028 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R2029 NRSA63J-152X MG RESISTOR 1.5k
Ω 1/16W J
R2030 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R2031 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R2032 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2034 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R2036 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R2037 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2039 NRSA63D-471X MG RESISTOR 470 Ω 1/16W D
R2040 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R2041 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R2042 NRSA63J-330X MG RESISTOR 33 Ω 1/16W J
R2043 NRSA63J-330X MG RESISTOR 33 Ω 1/16W J
R2044 NRSA63J-330X MG RESISTOR 33 Ω 1/16W J
R2046 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R2047 NRSA63J-330X MG RESISTOR 33 Ω 1/16W J
R2048 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R2049 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2050 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R2051 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2052 NRSA63J-683X MG RESISTOR 68k Ω 1/16W J
R2053 NRSA63J-683X MG RESISTOR 68k Ω 1/16W J
R2054 NRSA63J-683X MG RESISTOR 68k Ω 1/16W J
R2055 NRSA63J-683X MG RESISTOR 68k
Ω 1/16W J
R2201 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R2202 NRSA63D-153X MG RESISTOR 15k Ω 1/16W D
R2203 NRSA63D-222X MG RESISTOR 2.2k Ω 1/16W D
R2204 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2205 NRSA63J-680X MG RESISTOR 68 Ω 1/16W J
R2208 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
R2209 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
R2210 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
RA1001 NRZ0034-330W NET RESISTOR 33 Ω 1/32W J x4
RA1002 NRZ0034-330W NET RESISTOR 33 Ω 1/32W J x4
RA1003 NRZ0034-330W NET RESISTOR 33 Ω 1/32W J x4
RA1004 NRZ0034-330W NET RESISTOR 33 Ω 1/32W J x4
RA1005 NRZ0034-330W NET RESISTOR 33 Ω 1/32W J x4
RA1006 NRZ0034-330W NET RESISTOR 33 Ω 1/32W J x4
RA1007 NRZ0034-330W NET RESISTOR 33 Ω 1/32W J x4
RA1008 NRZ0034-330W NET RESISTOR 33 Ω 1/32W J x4
RA1401 NRZ0034-100W NET RESISTOR 10 Ω 1/32W J x4
RA1402 NRZ0034-100W NET RESISTOR 10 Ω 1/32W J x4
RA1403 NRZ0034-100W NET RESISTOR 10 Ω 1/32W J x4
RA1404 NRZ0034-100W NET RESISTOR 10 Ω 1/32W J x4
RA1405 NRZ0034-100W NET RESISTOR 10 Ω 1/32W J x4
RA1406 NRZ0034-100W NET RESISTOR 10 Ω 1/32W J x4
RA1407 NRZ0034-100W NET RESISTOR 10 Ω 1/32W J x4
RA2001 NRZ0034-330W NET RESISTOR 33 Ω 1/32W J x4
RA2002 NRZ0034-330W NET RESISTOR 33 Ω 1/32W J x4
RA2003 NRZ0034-330W NET RESISTOR 33 Ω 1/32W J x4
RA2004 NRZ0034-330W NET RESISTOR 33
Ω 1/32W J x4
RA2005 NRZ0034-330W NET RESISTOR 33 Ω 1/32W J x4
RA2006 NRZ0034-330W NET RESISTOR 33
Ω 1/32W J x4
L2001 NQL092K-1R0X P COIL 1uH K
L2002 NQL092K-1R0X P COIL 1uH K
L2003 NQL092K-1R0X P COIL 1uH K
L2201 NQL98EM-150X COIL 15uH M
L2202 NQL52EM-220X COIL 22uH M
CN1001 NNZ0132-001 MEMORY CARD CON
CN1002 NNZ0119-001 CF CARD CONNE
K1001 NQR0413-002X FERRITE BEADS
K1002 NQR0413-002X FERRITE BEADS
K1003 NQR0413-002X FERRITE BEADS
K1004 NQR0413-002X FERRITE BEADS
K1005 NQR0413-002X FERRITE BEADS
K1401 NQR0413-002X FERRITE BEADS
K1501 NQR0413-002X FERRITE BEADS
K2001 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K2002 NQR0413-002X FERRITE BEADS
K2003 NQR0413-002X FERRITE BEADS
K2004 NQR0413-002X FERRITE BEADS
K2201 NQR0413-002X FERRITE BEADS
X1001 NAX0587-001X CXO 54.0000MHz
 Ref No. Part No. Part Name Description Local
 Ref No. Part No. Part Name Description Local
IC9141 BA50BC0FP-X IC
 IC9211 FA5500AN-W IC
IC9501 F9222L-F219 IC
 IC9541 UTCTL431-T IC
IC9602 M62320FP-X IC
IC9901 MP1593DN-X IC
Q9021 2SC3928A/QR/-X TRANSISTOR
Q9211 2SK3522-01-F1 POWER MOS FET
Q9212 2SD601A/QR/-X TRANSISTOR
Q9213 IMD3A-W DIGI TRANSISTOR
Q9215 2SD601A/QR/-X TRANSISTOR
Q9216 UN2212-X DIGI TRANSISTOR
Q9251 UN2213-X DIGI TRANSISTOR
Q9252 UN2212-X DIGI TRANSISTOR
Q9501 2SD601A/QR/-X TRANSISTOR
Q9502 2SK2865-X POWER MOS FET
Q9503 2SD601A/QR/-X TRANSISTOR
Q9504 2SK2018-01S-W POWER MOS FET
Q9506 UN2213-X DIGI TRANSISTOR
Q9541 UN2212-X DIGI TRANSISTOR
Q9602 2SB1188/QR/-W TRANSISTOR
Q9603 UN2212-X DIGI TRANSISTOR
Q9604 UN2212-X DIGI TRANSISTOR
Q9606 2SC3928A/QR/-X TRANSISTOR
Q9608 2SB1188/QR/-W TRANSISTOR
Q9901 2SD601A/QR/-X TRANSISTOR
D9021 MA111-X SI DIODE
D9111 S1WB/A/60-4101 BRIDGE DIODE
 D9201 D25XB60 BRIDGE DIODE
D9202 MA111-X SI DIODE
D9205 MA3082/M/-X Z DIODE
D9211 YG972S6R SI DIODE
D9213 MA111-X SI DIODE
D9214 MA111-X SI DIODE
D9215 D1FL20U-X SI DIODE
D9251 MA3100/M/-X Z DIODE
D9252 MA111-X SI DIODE
D9253 MA111-X SI DIODE
D9254 D1FL20U-X SI DIODE
D9301 FME-220A SB DIODE
D9302 FME-220A SB DIODE
D9501 MA8220/M/-X Z DIODE
D9502 MA8110/H/-X Z DIODE
D9503 D1FL20U-X SI DIODE
D9504 D1FL20U-X SI DIODE
D9505 MA8220/M/-X Z DIODE
D9507 D1FL20U-X SI DIODE
D9508 UDZS5.6B-X Z DIODE 1.5k Ω 1/10W J
D9509 SD883-04-X SB DIODE
D9512 D1FS4-X SB DIODE
D9514 PTZ27B-X Z DIODE
D9515 PTZ27B-X Z DIODE
D9542 FCH20A10 SB DIODE
D9543 FCH20A10 SB DIODE
D9546 FCH20A10 SB DIODE
D9609 MA111-X SI DIODE
D9901 EC30HA04-X SB DIODE
D9902 MA111-X SI DIODE
D9903 EC30HA04-X SB DIODE
D9905 D1FL20U-X SI DIODE
D9906 PTZ11B-X Z DIODE
D9907 MTZJ16B-T2 Z DIODE
D9908 MTZJ16B-T2 Z DIODE
D9909 D1FL20U-X SI DIODE
 C9001 QFZ9072-105 MM CAPACITOR 1uF AC250V K
 C9002 QFZ9072-105 MM CAPACITOR 1uF AC250V K
 C9011 QCZ9071-102 C CAPACITOR 1000pF AC400V M
 C9013 QCZ9071-102 C CAPACITOR 1000pF AC400V M
 C9101 QCZ9078-472 C CAPACITOR 4700pF AC250V M
 C9102 QCZ9078-472 C CAPACITOR 4700pF AC250V M
 C9103 QCZ9078-472 C CAPACITOR 4700pF AC250V M
C9111 QEZ0709-106 E CAPACITOR 10uF 450V M
C9141 QECR1CM-477Z E CAPACITOR 470uF 16V M
C9142 QEHR1AM-337Z E CAPACITOR 330uF 10V M
C9143 QEHR1CM-107Z E CAPACITOR 100uF 16V M
 C9196 QCZ9071-471 C CAPACITOR 470pF AC400V K
 C9197 QCZ9071-102 C CAPACITOR 1000pF AC400V M
 C9198 QCZ9071-102 C CAPACITOR 1000pF AC400V M
 C9201 QCZ9078-222 C CAPACITOR 2200pF AC250V M
 C9203 QCZ9078-222 C CAPACITOR 2200pF AC250V M
 C9204 QCZ9078-222 C CAPACITOR 2200pF AC250V M
 C9205 QCZ9078-222 C CAPACITOR 2200pF AC250V M
C9211 QFZ0222-105 MM CAPACITOR 1uF 450V K
C9212 NCB31HK-103X C CAPACITOR 0.01uF 50V K
