JVC LT-Z37DX5 - Front Control P.w. Board Assy (Lca90469-04 A) (Sfl-7113 A); Front Led P.w. Board Assy (Lca90470-03 B) (Sfl-8133 A); Card P.w. Board Assy (Lca10556-03 A) (Sfl-8512 A)

(No.YA362)3-13
FRONT CONTROL P.W. BOARD ASS'Y
(LCA90469-04A) (SFL-7113A)
FRONT LED P.W. BOARD ASS'Y
(LCA90470-03B) (SFL-8133A)
CARD P.W. BOARD ASS'Y
(LCA10556-03A) (SFL-8512A)
R3611 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R3612 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R3613 NRSA63J-152X MG RESISTOR 1.5k
Ω 1/16W J
R3651 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R3652 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R3653 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R3654 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R3655 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R3656 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R3657 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R3658 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R4204 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R4301 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R4302 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R4303 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R4304 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R4305 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R4306 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R4307 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R4308 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R4401 NRSA63J-151X MG RESISTOR 150 Ω 1/16W J
R4402 NRSA63J-151X MG RESISTOR 150 Ω 1/16W J
R4403 NRSA63J-151X MG RESISTOR 150 Ω 1/16W J
R4404 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R4422 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R4424 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R4426 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R4501 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R4502 NRSA63J-220X MG RESISTOR 22 Ω 1/16W J
R4503 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R4504 NRSA63J-220X MG RESISTOR 22 Ω 1/16W J
R4505 NRSA63J-271X MG RESISTOR 270
Ω 1/16W J
L3001 NQL79GM-220X COIL 22uH M
L3002 NQL79GM-100X COIL 10uH M
L3503 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
L3504 NQL79GM-4R7X COIL 4.7uH M
L3506 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
L3507 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
CN0001 QGF0508F1-50X CONNECTOR FFC/FPC (1-50)
CN0002 QGF0508F1-30X CONNECTOR FFC/FPC (1-30)
CN1011 QGF0508F1-50X CONNECTOR FFC/FPC (1-50)
CN1012 QGF0508F1-50X CONNECTOR FFC/FPC (1-50)
K3501 NQR0389-003X FERRITE BEADS
K3502 NQR0389-003X FERRITE BEADS
LC3501 NQR0431-001X EMI FILTER 0.22uF 50V Z
 TU3001 QAU0390-001 TUNER
X3501 QAX0773-001Z CRYSTAL 18.432000MHz
 Ref No. Part No. Part Name Description Local
D7011 UDZS6.2B-X Z DIODE
C7011 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C7012 NCB31HK-104X C CAPACITOR 0.1uF 50V K
R7011 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R7012 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R7013 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R7014 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R7015 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R7016 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R7018 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7701 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R7702 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R7703 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R7704 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
L7001 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
L7002 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
J7001 QNS0097-001 3.5 JACK HEADPHONE
K7001 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
S7701 QSW1131-001Z TACT SWITCH CH-
S7702 QSW1131-001Z TACT SWITCH CH+
S7703 QSW1131-001Z TACT SWITCH MENU/OK
S7704 QSW1131-001Z TACT SWITCH TV/VIDEO
S7705 QSW1131-001Z TACT SWITCH VOL+
S7706 QSW1131-001Z TACT SWITCH VOL-
S7707 QSW1131-001Z TACT SWITCH POWER
 Ref No. Part No. Part Name Description Local
 Ref No. Part No. Part Name Description Local
IC8752 GP1UM261RK IR DETECT UNIT
Q8703 UN2212-X DIGI TRANSISTOR
Q8704 UN2110-X DIGI TRANSISTOR
Q8710 UN2212-X DIGI TRANSISTOR
Q8711 UN2212-X DIGI TRANSISTOR
D8702 SEL5E20C-T LED POWER
D8705 SELU5E20C-T LED ILLUMINATION
D8706 MA8068-X Z DIODE
D8707 MA8068-X Z DIODE
D8708 MA8068-X Z DIODE
D8709 MA8068-X Z DIODE
C8752 NEHL1CM-476X E CAPACITOR 47uF 16V M
R8713 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R8714 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R8721 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R8722 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
R8724 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R8726 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R8755 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
 Ref No. Part No. Part Name Description Local
IC1001 ES6425FDF IC
IC1002 IC-PST596N/J/-X IC
IC1003 SN74LVC1G126V-X IC
IC1005 RPI-352 PHOTO TRANSISTOR
IC1006 SN74LVC2G74T-X IC
IC1007 SN74LVC2G241T-X IC
IC1201 SN74LVC244APW-X IC
IC1202 SN74LVC1G04V-X IC
IC1203 SN74LVC1G08V-X IC
IC1401 K4S281632F-UC75 IC(DIGITAL)
IC2001 ADV7125KST140 IC
IC2002 AK4384VT-X IC
IC2003 NJM4580V-X IC
IC2004 XC9572L10VG6401 IC(MICRO C ROM)
IC2005 SN74LVC2G08T-X IC
IC2201 R1170H331B-X IC
IC2202 MP1580HS-X IC
IC2204 MM1562AF-X IC
Q1201 2SB1188/QR/-W TRANSISTOR
Q1202 UN2213-X DIGI TRANSISTOR
Q2201 2SC2411K/QR/-X TRANSISTOR
D1201 MA111-X SI DIODE
D1202 MA111-X SI DIODE
D1203 MA111-X SI DIODE
D1204 MA111-X SI DIODE
D2201 PTZ3.9B-X Z DIODE
D2202 EC30HA03L-X SB DIODE
C1001 NBZ0007-107X SP E CAPACITOR 100uF 4V M
C1002 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C1003 NBZ0007-107X SP E CAPACITOR 100uF 4V M
C1004 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C1005 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C1006 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C1007 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C1008 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C1009 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C1010 NDC31HJ-101X C CAPACITOR 100pF 50V J
C1011 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C1012 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C1016 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C1017 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C1018 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C1019 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C1020 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C1021 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C1022 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C1025 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C1026 NEHM0JM-336X E CAPACITOR 33uF 6.3V M
C1027 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C1028 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C1029 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
