JVC LT-Z37DX5 - Panel I;F P.w. Board Assy (Lca10652-01 A) (Sfl-0 H001 A)

(No.YA362)3-23
PANEL I/F P.W. BOARD ASS'Y
(LCA10652-01A) (SFL-0H001A)
RA3506 NRZ0040-510X NET RESISTOR 51 Ω 1/16W J x4
RA3508 NRZ0080-510X NET RESISTOR 51 Ω 1/16W J
RA3512 NRZ0080-510X NET RESISTOR 51
Ω 1/16W J
RA3516 NRZ0040-510X NET RESISTOR 51
Ω 1/16W J x4
RA3518 NRZ0040-510X NET RESISTOR 51 Ω 1/16W J x4
RA3521 NRZ0080-510X NET RESISTOR 51 Ω 1/16W J
RA3523 NRZ0040-510X NET RESISTOR 51 Ω 1/16W J x4
RA3526 NRZ0080-510X NET RESISTOR 51 Ω 1/16W J
RA3530 NRZ0040-510X NET RESISTOR 51 Ω 1/16W J x4
RA3531 NRZ0080-510X NET RESISTOR 51
Ω 1/16W J
RA3536 NRZ0080-510X NET RESISTOR 51 Ω 1/16W J
RA3540 NRZ0040-510X NET RESISTOR 51
Ω 1/16W J x4
RA3542 NRZ0040-510X NET RESISTOR 51 Ω 1/16W J x4
RA3545 NRZ0080-510X NET RESISTOR 51 Ω 1/16W J
RA3547 NRZ0040-510X NET RESISTOR 51 Ω 1/16W J x4
RA4007 NRZ0034-101W NET RESISTOR 100 Ω 1/32W J x4
RA4008 NRZ0034-101W NET RESISTOR 100 Ω 1/32W J x4
RA4009 NRZ0034-101W NET RESISTOR 100
Ω 1/32W J x4
RA4010 NRZ0034-101W NET RESISTOR 100
Ω 1/32W J x4
RA4011 NRZ0034-101W NET RESISTOR 100 Ω 1/32W J x4
RA4012 NRZ0034-101W NET RESISTOR 100 Ω 1/32W J x4
RA6515 NRZ0034-0R0W NET RESISTOR 0 Ω 1/32W J x4
RA7001 NRZ0040-101X NET RESISTOR 100 Ω 1/16W J x4
RA7007 NRZ0040-0R0X NET RESISTOR 0 Ω 1/16W J x4
RA7501 NRZ0080-510X NET RESISTOR 51
Ω 1/16W J
RA7502 NRZ0080-510X NET RESISTOR 51 Ω 1/16W J
RA7503 NRZ0040-0R0X NET RESISTOR 0
Ω 1/16W J x4
RA7504 NRZ0080-510X NET RESISTOR 51 Ω 1/16W J
RA7505 NRZ0080-510X NET RESISTOR 51 Ω 1/16W J
L0101 NQL092K-R68X P COIL 0.68uH K
L0102 NQL092K-1R0X P COIL 1uH K
L0201 NQL092K-R68X P COIL 0.68uH K
L0202 NQL092K-1R0X P COIL 1uH K
L0301 NQL092K-R68X P COIL 0.68uH K
L0302 NQL092K-1R0X P COIL 1uH K
L0401 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
L1001 NQR0489-002X FERRITE BEADS
L1002 NQR0489-002X FERRITE BEADS
L1003 NQL092K-1R5X P COIL 1.5uH K
L1004 NQR0489-002X FERRITE BEADS
L1005 NQR0489-002X FERRITE BEADS
L1006 NQR0489-002X FERRITE BEADS
L1008 NQL79GM-220X COIL 22uH M
L1010 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
L1011 NQL79GM-470X COIL 47uH M
L1101 NQL092K-6R8X P COIL 6.8uH K
L1102 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
L1103 NQL093K-1R0X P COIL 1uH K
L1104 NQL093K-R10X P COIL 0.1uH K
L1201 NQL092K-6R8X P COIL 6.8uH K
L1203 NQL092K-1R0X P COIL 1uH K
L1301 NQL092K-3R3X P COIL 3.3uH K
L1303 NQL092K-1R0X P COIL 1uH K
L1304 NQL093K-R10X P COIL 0.1uH K
L1401 NQL092K-3R3X P COIL 3.3uH K
L1403 NQL092K-1R0X P COIL 1uH K
L1404 NQL093K-R10X P COIL 0.1uH K
L1501 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
L1533 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
L1534 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
L3005 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
L3006 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
L3008 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
L3009 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
L3010 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
L3011 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
L3012 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
L3013 NQL093K-R10X P COIL 0.1uH K
L3014 NQL093K-R10X P COIL 0.1uH K
L3015 NQL093K-R10X P COIL 0.1uH K
L3501 NQR0413-003X FERRITE BEADS
L4001 NQR0413-003X FERRITE BEADS
L4002 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
L4003 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
L6501 NQR0351-001X FERRITE BEADS
L6502 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
L6508 NRZ0034-0R0W NET RESISTOR 0
Ω 1/32W J x4
L6509 NRZ0034-0R0W NET RESISTOR 0 Ω 1/32W J x4
L6510 NRZ0034-0R0W NET RESISTOR 0 Ω 1/32W J x4
L7001 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
L7002 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
L7003 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
L7004 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
L7005 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
L7006 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
L7510 NQL092K-4R7X P COIL 4.7uH K
L7512 NQR0489-002X FERRITE BEADS
L7513 NQR0489-002X FERRITE BEADS
L9001 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
 Ref No. Part No. Part Name Description Local
L9002 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
L9201 NQL71EM-150X COIL 15uH M
CN001 QGF0508F1-50X CONNECTOR FFC/FPC (1-50)
CN002 QGF0508F1-30X CONNECTOR FFC/FPC (1-30)
J001 NNZ0117-001 HDMI CONNECTOR DIGITAL IN
K1001 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K1002 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K1003 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K1004 NQR0489-002X FERRITE BEADS
K1005 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
K3003 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K3006 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K3009 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K3191 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K7502 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K7503 NQR0389-003X FERRITE BEADS
K9001 NQR0413-003X FERRITE BEADS
K9002 NQR0413-003X FERRITE BEADS
LC0102 NQR0483-005X EMI FILTER 100uF 25V Z
LC0519 NQR0416-001X EMI FILTER 240pF 16V M
LC0522 NQR0470-007X EMI FILTER 2200pF 50V +50%-20%
LC0524 NQR0483-005X EMI FILTER 100uF 25V Z
LC0527 NQR0483-006X EMI FILTER
LC6501 NQR0479-001X EMI FILTER
LC7004 NQR0483-003X EMI FILTER
LC7501 NQR0483-006X EMI FILTER
LC7502 NQR0483-006X EMI FILTER
SL7001 NAX0613-001X C RESONATOR
X1001 NAX0642-001X CRYSTAL
X3001 NAX0635-001X CXO
X3003 NAX0668-001X CXO
X4001 NAX0669-001X C RESONATOR
X7501 NAX0618-001X CRYSTAL
 Ref No. Part No. Part Name Description Local
IC5001 JCC5064 IC
IC5002 K4S643232H-UC60 IC
IC5003 K4S643232H-UC60 IC
IC5005 S-80828CLNB-G-W IC
IC5101 MP1593DN-X IC
IC5111 MP1593DN-X IC
IC5121 MP1593DN-X IC
IC5172 NAX0637-001X CXO 74.1758MHz
IC5181 THC63LVD103 IC
Q5001 UN2213-X DIGI TRANSISTOR
D5101 EC30HA04-X SB DIODE
D5103 PTZ3.9B-X Z DIODE
D5111 EC30HA04-X SB DIODE
D5113 PTZ3.9B-X Z DIODE
D5121 EC30HA04-X SB DIODE
D5122 EC30HA04-X SB DIODE
D5123 PTZ6.8B-X Z DIODE
C5001 NCB11AK-106X C CAPACITOR 10uF 10V K
C5002 NCB11AK-106X C CAPACITOR 10uF 10V K
C5003 NCB11AK-106X C CAPACITOR 10uF 10V K
C5004 NCB11AK-106X C CAPACITOR 10uF 10V K
C5005 NCB11AK-106X C CAPACITOR 10uF 10V K
C5006 NCB11AK-106X C CAPACITOR 10uF 10V K
C5007 NCB11AK-106X C CAPACITOR 10uF 10V K
C5011 NCB11AK-106X C CAPACITOR 10uF 10V K
C5013 NCB11AK-106X C CAPACITOR 10uF 10V K
C5014 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C5015 NCB31AK-105X C CAPACITOR 1uF 10V K
C5016 NCB31HK-102X C CAPACITOR 1000pF 50V K
C5017 NCB31HK-102X C CAPACITOR 1000pF 50V K
C5018 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C5019 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C5024 NCB31AK-105X C CAPACITOR 1uF 10V K
C5027 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C5028 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C5029 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C5030 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C5031 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C5032 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C5033 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C5034 NCB31HK-102X C CAPACITOR 1000pF 50V K
C5035 NCB31HK-102X C CAPACITOR 1000pF 50V K
C5036 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C5037 NCB31HK-104X C CAPACITOR 0.1uF 50V K
 Ref No. Part No. Part Name Description Local
