JVC LT-Z37DX5 - Printed Wiring Board Parts List [Lt-Z37 Dx5;A]; Analog Signal P.w. Board Assy (Lca90537-03 A) (Sfl-1133 A); Receiver P.w. Board Assy (Lca90581-01 A) (Sfl-4133 A); Front Control P.w. Board Assy (Lca90469-04 A) (Sfl-7113 A)

(No.YA362)3-25
PRINTED WIRING BOARD PARTS LIST [LT-Z37DX5/A]
ANALOG SIGNAL P.W. BOARD ASS'Y
(LCA90537-03A) (SFL-1133A)
REFER TO PARTS LIST IN PAGE 3-8 FOR THIS P.W. BOARD.
RECEIVER P.W. BOARD ASS'Y
(LCA90581-01A) (SFL-4133A)
REFER TO PARTS LIST IN PAGE 3-12 FOR THIS P.W. BOARD.
FRONT CONTROL P.W. BOARD ASS'Y
(LCA90469-04A) (SFL-7113A)
REFER TO PARTS LIST IN PAGE 3-13 FOR THIS P.W. BOARD.
FRONT LED P.W. BOARD ASS'Y
(LCA90470-03B) (SFL-8133A)
REFER TO PARTS LIST IN PAGE 3-13 FOR THIS P.W. BOARD.
CARD P.W. BOARD ASS'Y
(LCA10556-03A) (SFL-8512A)
REFER TO PARTS LIST IN PAGE 3-13 FOR THIS P.W. BOARD.
MAIN POWER P.W. BOARD ASS'Y
(LCA90463-21A) (SFL-9039A)
REFER TO PARTS LIST IN PAGE 3-15 FOR THIS P.W. BOARD.
REGULATOR P.W. BOARD ASS'Y
(LCA90464-19A) (SFL-9138A)
REFER TO PARTS LIST IN PAGE 3-17 FOR THIS P.W. BOARD.
DIGITAL SIGNAL P.W. BOARD ASS'Y
(LCA10557-87A) (SFL-0D345A)
 Ref No. Part No. Part Name Description Local
IC0401 SN74AHCT1G32V-X IC
IC1001 TC90A92AFG IC
IC1002 MM1572FN-X IC
IC1003 R1141Q151D-X IC
IC1005 ML87V2105TBZ03A IC
IC1502 NJM2235V-X IC
IC3001 JCC5055A IC
IC3004 TC7MB3257FK-X IC
IC3005 SN74LVC1G08V-X IC
IC3006 SN74LVC2G126T-X IC
IC3007 SN74LVC3G17U-X IC
IC3008 R1170H331B-X IC
IC3191 SN74LVC3G17U-X IC
IC3403 S-80928CLNB-G-W IC
IC3501 EDD1232AAFA-7A IC
IC3502 EDD1232AAFA-7A IC
IC3503 LP2996MR-X IC
IC4001 JCC5057 IC
IC4003 AT29LE-Z37DX5 IC(MICRO C ROM) (SERVICE)
IC4004 ATF256-Z37DX5 IC (SERVICE)
IC6502 THC63LVDM83R-W IC
IC7001 MN102H60KKP IC(MCU)
IC7002 ATF512-Z37DX5 IC(MICRO C ROM) (SERVICE)
IC7003 SN74LVC2G241T-X IC
IC7401 S-80928CLNB-G-W IC
IC7501 SDA6000-B12 IC
IC7502 S-80828CNNB-G-W IC
IC7503 K4S641632H-UC75 IC
IC7504 MBV160-Z37DX5 IC (SERVICE)
IC7505 PQ2L3252MS-X IC
IC7506 CD74HC4053PW-X IC
IC7602 ATF32-Z37DX5 IC (SERVICE)
IC9201 MP1593DN-X IC
Q0101 2SC3837K/NP/-X TRANSISTOR
Q0102 2SA1022/BC/-X TRANSISTOR
Q0104 2SA1022/BC/-X TRANSISTOR
Q0105 2SC3928A/QR/-X TRANSISTOR
Q0107 2SA1530A/QR/-X TRANSISTOR
Q0108 2SC3928A/QR/-X TRANSISTOR
Q0109 HN1C01F/Y/-X PAIR TRANSISTOR
Q0110 HN1C01F/Y/-X PAIR TRANSISTOR
Q0201 2SC3837K/NP/-X TRANSISTOR
Q0202 2SA1022/BC/-X TRANSISTOR
Q0203 2SC3928A/QR/-X TRANSISTOR
Q0204 2SA1022/BC/-X TRANSISTOR
Q0205 2SC3928A/QR/-X TRANSISTOR
Q0206 2SC3928A/QR/-X TRANSISTOR
Q0207 2SA1530A/QR/-X TRANSISTOR
Q0208 2SC3928A/QR/-X TRANSISTOR
Q0209 HN1C01F/Y/-X PAIR TRANSISTOR
Q0210 HN1C01F/Y/-X PAIR TRANSISTOR
Q0301 2SC3837K/NP/-X TRANSISTOR
Q0302 2SA1022/BC/-X TRANSISTOR
Q0303 2SC3928A/QR/-X TRANSISTOR
Q0304 2SA1022/BC/-X TRANSISTOR
Q0305 2SC3928A/QR/-X TRANSISTOR
Q0306 2SC3928A/QR/-X TRANSISTOR
Q0307 2SA1530A/QR/-X TRANSISTOR
Q0308 2SC3928A/QR/-X TRANSISTOR
Q0309 HN1C01F/Y/-X PAIR TRANSISTOR
Q0310 HN1C01F/Y/-X PAIR TRANSISTOR
Q0311 2SC3928A/QR/-X TRANSISTOR
Q1001 UN2213-X DIGI TRANSISTOR
Q1003 2SC3928A/QR/-X TRANSISTOR
Q1004 2SC3928A/QR/-X TRANSISTOR
Q1005 2SK1228-X MOS FET
Q1006 2SK1228-X MOS FET
Q1101 2SC3928A/QR/-X TRANSISTOR
Q1103 2SA1530A/QR/-X TRANSISTOR
Q1201 2SC3928A/QR/-X TRANSISTOR
Q1203 2SA1530A/QR/-X TRANSISTOR
Q1301 2SC3928A/QR/-X TRANSISTOR
Q1303 2SA1530A/QR/-X TRANSISTOR
Q1401 2SC3928A/QR/-X TRANSISTOR
Q1403 2SA1530A/QR/-X TRANSISTOR
Q3001 2SC3928A/QR/-X TRANSISTOR
Q3002 2SA1530A/QR/-X TRANSISTOR
Q3003 2SC3928A/QR/-X TRANSISTOR
Q3004 2SA1530A/QR/-X TRANSISTOR
Q4001 2SC3928A/QR/-X TRANSISTOR
Q6501 2SC3928A/QR/-X TRANSISTOR
Q7206 UN2213-X DIGI TRANSISTOR
Q7207 UN2113-X TRANSISTOR
Q7208 UN2113-X TRANSISTOR
Q7209 UN2113-X TRANSISTOR
Q7501 2SA1162/YG/-X TRANSISTOR
Q7508 DTC114EKA-X DIGI TRANSISTOR
D1001 EC30HA03L-X SB DIODE
D1002 EC30HA03L-X SB DIODE
D2103 1SS355-X SI DIODE
D7001 1SS355-X SI DIODE
D7003 RB501V-40-X SB DIODE
D7005 UDZS8.2B-X Z DIODE
D7006 UDZS8.2B-X Z DIODE
D7007 UDZS8.2B-X Z DIODE
D7008 UDZS8.2B-X Z DIODE
D7009 UDZS8.2B-X Z DIODE
D7203 1SS355-X SI DIODE
D7501 1SS355-X SI DIODE
D7502 1SS355-X SI DIODE
D9201 EC30HA04-X SB DIODE
D9203 PTZ3.9B-X Z DIODE
D9204 1SS355-X SI DIODE
C0104 NDC31HJ-390X C CAPACITOR 39pF 50V J
C0105 NDC31HJ-330X C CAPACITOR 33pF 50V J
C0107 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C0109 NCB11AK-106X C CAPACITOR 10uF 10V K
C0110 NCB11AK-106X C CAPACITOR 10uF 10V K
C0111 NDC31HJ-820X C CAPACITOR 82pF 50V J
C0112 NDC31HJ-820X C CAPACITOR 82pF 50V J
C0113 NCB11AK-106X C CAPACITOR 10uF 10V K
C0114 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C0115 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C0116 NCB11AK-106X C CAPACITOR 10uF 10V K
 Ref No. Part No. Part Name Description Local
