DN112-06v02
JYE Tech - 26 - www.jyetech.com
Bit[7]: 1 – Perform VPos alignment.. 0 – No effect
Bit[6]: 1 – Restore factory default. 0 – No effect.
Bit[5]: 1 – Execute preset save or recall depending on the
preset byte at offset 6 (see below).
Bit[4:0]: Reserved. Must be 0b00000.
Measurement:
Bit[7]: ΔT cursor control. 1 – ON. 0 – OFF.
Bit[6]: ΔV cursor control. 1 – ON. 0 – OFF.
Bit[5]: Voltage measurements control. 1 – ON. 0 – OFF.
Bit[4]: Frequency measurement control. 1 – ON. 0 – OFF.
Bit[3:1]: Reserved. Must 0b000.
Bit[0]: Measurement output. 1 – Send measurements to
serial port. 0 --- Do not send measurements.
Preset:
Bit[7]: 1 – Recall the preset specified by Bit[6:0]. 0 – Load
the preset specified by Bit[6:0].
Bit[6:0]: Index to the location where preset is to be recalled
or saved. Valid range is 0 – 23.
