Technical Specification
1 --- 1
1 Technical Specification
1.1 Compressor Unit
Model CSD 75..........................................
Maximum gauge working pressure 125 psig....................
Minimum gauge working pressure 80 psig......................
Free air delivery at max. gauge 361 cfm........................
working pressure
Operating temperature approx. 167 --- 200 EF..................
(Varies with ambient temperature and operating conditions)
Weight2870lbs............................................
Drawings:
Dimensional drawing T 9901.00...........................
P & I flow chart FCSDSTL---0001.00.......................
(Pipework and instrument flow chart)
Electrical diagram SCSD75.L---U1051.00....................
1.2 Noise Level
Noise level to CAGI---Pneurop 69 dB(A)..........................
at 1 m distance (free sound field measurement)
1.3 Motor
Compressor motor:
Rated power 75 hp.........................................
Rated speed 3600 rpm.......................................
Specification class TEFC.................................
Fan motor:
Rated power 1.3 hp........................................
Rated speed 1200 rpm.......................................
Specification class TEFC.................................
1.4 Electrical Connection
Main voltage 460 V 3---phase........................................
Full load current FLA 98 A..................................
Frequency 60 Hz...........................................
Recommended main disconnect fuses
(Dual element or time---delay) 125 A.........................
Recommended power supply cable (Cu multi---stranded )
cross---section 1/0 AWG.......................................
Maximum dual element time--delay fuses are selected according to
1996 N.E.C. Article 240--6, 430--52 and Tables 430--148 & 150.
Select multi--strand copper core wire at 40C ambient temperature
according to 1996 N.E.C. 110--14(c), 220--3, 310--15, Table 310--16,
430--6, 430--22 and Tables 430--148 & 150.
For electrical power supply please refer to chapter 2.3 and 6.3
Attention!
