8. Install the left and right pull plate and left and right cover on brew unit frame, oil
(MI-setral-61B) coating position for left and right pull plate should be as the picture shows.
8 8
9. Install the brew unit top cover.
9
1 1
1
Note: Pay attention to the direction
of the brew unit top cover, the
deeper groove should be in front.
10. Lock the left side and right side cover
screws.
10 10
1
1
57
Repair
