Kamstrup MULTICAL 602 Technical Description

MULTICAL®602
KamstrupA/S∙TechnicalDescription∙5512‐931_N1_GB
_
11.2016
105
11.1.1 MULTICAL

602 Register ID’s
ID Register Description
1003 DATE Current date (YYMMDD)
60 E1 Energy register 1: Heat energy
94 E2 Energy register 2: Control energy
63 E3 Energy register 3: Cooling energy
61 E4 Energy register 4: Inlet
energy
(forwarded energy)
62 E5 Energy register 5: Outlet energy (returned energy)
95 E6 Energy register 6: Tap water energy
96 E7 Energy register 7: Heat energy Y
97 E8
Energy register 8: m
3
x T1
110 E9
Energy register 9: m
3
x T2
64 TA2 Tariff register 2
65 TA3 Tariff register 3
68 V1 Volume register V1
69 V2 Volume register V2
84 VA Input register VA
85 VB Input register VB
72 M1 Mass register V1
73 M2 Mass register V2
1004 HR Operational hour counter
113 INFOEVEN
T
Info-event counter
1002 CLOC
K
Current time (hhmmss)
99 INFO Infocode register, current
86 T1 Current inlet
temperature
87 T2 Current outlet
temperature
88 T3 Current temperature T3
122 T4 Current temperature T4
89 T1-T2 Current temperature difference
91 P1 Pressure in inlet
29 P2 Pressure in outlet
74 FLOW1 Current flow in inlet
pipe
75 FLOW2 Current flow in outlet pipe
80 EFFEKT1 Current power calculated on the basis of V1-T1-T2
123 MAX FLOW1DATE/
Å
R Date for max. this year
124 MAX FLOW1/
Å
R Max. value this year
125 MIN FLOW1DATE/
Å
R Date for min. this year
126 MIN FLOW1/
Å
R Min. value this year
127 MAX EFFEKT1DATE/
Å
R Date for max. this year
128 MAX EFFEKT1/
Å
R Max. value this year
129 MIN EFFEKT1DATE/
Å
R Date for min. this year
130 MIN EFFEKT1/
Å
R Min. value this year
138 MAX FLOW1DATE/M
Å
NED Date for max. this month
139 MAX FLOW1/M
Å
NED Max. value this month
140 MIN FLOW1DATE/M
Å
NED Date for min. this month
141 MIN FLOW1/M
Å
NED Min. value this month
142 MAX EFFEKT1DATE/M
Å
NED Date for max. this month
143 MAX EFFEKT1/M
Å
NED Max. value this
month
144 MIN EFFEKT1DATE/M
Å
NED Date for min. this month
145 MIN EFFEKT1/M
Å
NED Min. value this month
146 AVR T1/
Å
R Year-to-date average for T1
147 AVR T2/
Å
R Year-to-date average for T2
149 AVR T1/M
Å
NED Month-to-date average for T1
150 AVR T2/M
Å
NED Month-to-date average for T2
66 TL2 Tariff limit 2
67 TL3 Tariff limit 3
98 XDAY Target date (reading date)
152 PROG NO Program no. ABCCCCCC
153 CONFIG NO 1
Config no. DDDEE
168 CONFIG NO 2
Config. no. FFGGMN
1001 SERIE NO Serial no.
(unique number for each meter)
112 METER NO 2
Customer number (8 most important digits)
1010 METER NO 1
Customer number (8 less important digits)
114 METER NO VA
Meter no. for VA
104 METER NO VB
Meter no. for VB
1005 METER TYPE
Software edition
154 CHECK SUM 1
Software check sum
155 HIGH RES High-resolution energy register for testing purposes
157 TOPMODUL ID ID number for top module
158 BOTMODUL ID ID number for base module
175 INFOHOUR Error hour counter
234 IMPINa l/imp. for VA
235 IMPINb l/imp. for VB

Kamstrup MULTICAL 602 Specifications

General

Flow Sensor	Ultrasonic
Display	LCD
Battery Life	Up to 16 years
Communication	M-Bus, Wireless M-Bus
Approval	MID class 2, EN 1434
Accuracy	Class 2
Pressure Rating	PN16
Application	Heating and cooling systems
Temperature Range	0°C to 180°C
