18 Appendix A - MULTICAL

602 vs. previous meters
This paragraph briefly describes the compatibility with other/previous meters. The description is not final.
18.1 Kamstrup Meter Protocol (KMP)
MULTICAL
®
602 uses Kamstrup’s Meter Protocol (KMP) and, thus, has the same communication platform as
MULTICAL
®
402/61/601/801. KMP is used internally in the meter as well as via the optical eye and contact pins for
the base module. Thus, base modules with e.g. M-Bus interface use the KMP protocol internally and the M-Bus
protocol externally. Further information on the KMP protocol appears from paragraph 11.1.
18.2 M-Bus module with MULTICAL
®
III compatible data packet (67-00-29)
A variety of M-Bus modules are available for the Kamstrup MULTICAL
®
61/601/801 meters. The contents of the
module’s M-Bus data package are similar to the data of the M-Bus modules for MULTICAL
®
III and MULTICAL
®
Compact, allowing installation in older applications originally designed for e.g. MULTICAL
®
III.
The module can also be used together with the old 40-slave M-Bus Master with display from Kamstrup as well as
older regulators and reading software. The module is mounted in the meter’s module area and is
used for remote reading and programming of MULTICAL
®
61/601/602/801.
18.3 SIOX module (602-00-64)
The SIOX module can be used in a series of Kamstrup’s meters, e.g. MULTICAL
®
61/601/602/801, making it
possible to read meter data via the SIOX-bus. The SIOX-bus is a well-known bus-system, which has been used in
many meter relations. This module makes it possible to use MULTICAL
®
61/601/602/801 in a SIOX-network.
18.4 MULTICAL
®
66-C compatibility module (67-06)
Concerning MULTICAL
®
601 a top module made MULTICAL
®
601 data compatible with MULTICAL
®
66-C, making it
possible to use a series of previous base modules for MULTICAL
®
66-C in MULTICAL
®
601 too. This module has been
discontinued and does not function together with MULTICAL
®
602.
19 Appendix B - MULTICAL

602 vs. MULTICAL

6L2
MULTICAL
®
6L2 is a light version of the MULTICAL
®
602 and this paragraph briefly describes the differences between
the two. Please note that this paragraph only describes the differences between the two calculators and not the
similarities. For further information about the MULTICAL
®
6L2 please see the calculators datasheet.
Besides the differences shown below there is another major difference worth noticing. The MULTICAL
®
6L2 has only
got a main-key and no sub-key. With only a main-key, it is no longer a possible to setup or reset the meter via the
front keys. Neither can the communication modules be initialized or the M-Bus address changed. Furthermore with
no sub-key the dataloggers can not be viewed on the display.
MULTICAL
®
602 MULTICAL
®
6L2
Type approval
√ √
Top module
√ -
Wired communication
√ √
Wireless communication
√ -
1 pcs. ULTRAFLOW
®
√ √
2 pcs. ULTRAFLOW
®
√ -
3
rd
party flow meters
√ -
