Kamstrup MULTICAL 602 User Manual

5Kamstrup A/S • 5512952_C6_GB_07.2015
MULTICAL® 602 & ULTRAFLOW®
2 Mounting of temperture sensors
The temperture sensors used to mesure inlet nd outlet tempertures respectively re 
mtched sensor pir tht must never be seprted.
Temperture sensors re usully mounted in MULTICAL® 602 from the fctory. According to EN
1434 or OIML R75 the cble length must not be chnged. If necessry, sensors must lwys be
replced in pirs.
The sensor mrked with  red sign is to be instlled in the inlet pipe. The other sensor mrked with
 blue sign is to be instlled in the outlet pipe (see prgrph 5, pge 12).
Note: The sensor cbles must not be pulled. Be wre of this in cse of binding the cbles.
2.1 Pocket sensor pir
Preferbly, sensor pockets must be mounted in tee-pieces or in
45° lterl Y-pieces. The tip of the sensor pocket must be plced
in the middle of the wter flow.
The temperture sensors should rech the bottom of the
pockets. If  short response time is required, “non-hrdening”
het conducting pste cn be used.
Push the plstic sleeve on the sensor cble into the sensor
pocket nd secure the cble by mens of the enclosed M4
seling screw. Fsten the screw with your fingers only. Sel the
pockets using sel nd locking wire.

Kamstrup MULTICAL 602 Specifications

General

Flow Sensor	Ultrasonic
Display	LCD
Battery Life	Up to 16 years
Communication	M-Bus, Wireless M-Bus
Approval	MID class 2, EN 1434
Accuracy	Class 2
Pressure Rating	PN16
Application	Heating and cooling systems
Temperature Range	0°C to 180°C
