MULTICAL® 602 & ULTRAFLOW®
3.3 Instlltion exmples
Threded meters with MULTICAL® mounted on ULTRAFLOW®.
Flow from the left
Type 65-5-XXAX-XXX
Flow from the right
Type 65-5-XXHX-XXX
Flnge meter with MULTICAL® mounted on ULTRAFLOW®.
Flow from the left Flow from the right
MULTICAL® 602 cn be mounted in two positions
by mens of n ngle fitting.
Angle fitting type 30-26-252 is ordered seprtely.
3.3.1 Humidity nd condenstion
If ULTRAFLOW® is instlled in moist environments, it must be turned 45° round the pipe xis s
shown in the drwing below.
If there is risk of condenstion, e.g. in
cooling systems,  condenstion protected
ULTRAFLOW® must be used.
45°

Kamstrup MULTICAL 602 Specifications

General

Flow Sensor	Ultrasonic
Display	LCD
Battery Life	Up to 16 years
Communication	M-Bus, Wireless M-Bus
Approval	MID class 2, EN 1434
Accuracy	Class 2
Pressure Rating	PN16
Application	Heating and cooling systems
Temperature Range	0°C to 180°C
