MULTICAL® 602 & ULTRAFLOW®
4 Mounting of clcultor
The MULTICAL® 602 clcultor cn be mounted in three different wys:
4.1 Compct mounting
The clcultor is mounted direct on the flow sensor, e.g. vi n ngle fitting. Hving been
mounted the clcultor is seled with sel nd thred. In cse of strong condenstion (e.g.
cooling pplictions) we recommend wll mounting of the clcultor. Also see point 3.1 Mounting
ULTRAFLOW® ≤ DN125, page 9.
4.2 Seprte/wll mounting
In connection with mounting in condensing
environments s well s in order to prolong the
bttery lifetime, we recommend the use of 
wll fitting.
The wll fitting mkes it possible to mount
MULTICAL® 602 direct on n even wll. Use the
fitting s  templte to mrk nd drill two 6 mm
holes in the wll.
52 mm
4.3 Pnel mounting
MULTICAL® 602 cn be mounted direct in pnels nd control pnels, vi Kmstrup’s pnel
mounting kit, No. 66-99-104 (192 x 144 mm).

Kamstrup MULTICAL 602 Specifications

General

Flow Sensor	Ultrasonic
Display	LCD
Battery Life	Up to 16 years
Communication	M-Bus, Wireless M-Bus
Approval	MID class 2, EN 1434
Accuracy	Class 2
Pressure Rating	PN16
Application	Heating and cooling systems
Temperature Range	0°C to 180°C
