4 Kamstrup A/S • 5512952_C6_GB_07.2015
MULTICAL® 602 & ULTRAFLOW®
Contents
1 Generl informtion 4
2 Mounting of temperture sensors 5
2.1 Pocket sensor pir 5
2.2 Short direct temperture sensor pir 6
3 Mounting of flow sensor 7
3.1 Mounting ULTRAFLOW® ≤ DN125 9
3.2 Mounting of ULTRAFLOW® 54 ≥ DN150 9
3.3 Instlltion exmples 10
4 Mounting of clcultor 11
4.1 Compct mounting 11
4.2 Seprte/wll mounting 11
4.3 Pnel mounting 11
5 Electricl connection, MULTICAL® nd
ULTRAFLOW® 12
5.1 Connection exmple 13
5.2 Het meter with two flow sensors 14
5.3 Electricl connection of
Pulse Trnsmitter 15
6 Voltge supply of clcultor/
Pulse Trnsmitter 15
6.1 Bttery supply 15
6.2 Mins modules 15
7 Testing of function 16
8 Informtion codes ”INFO” 17
9 Plug-in modules 18
9.1 Top modules 18
9.2 Bse modules 20
9.3 Module overview 24
10 Setup vi front keys 25
1 Generl informtion
Red this guide before instlling the meter.
Kmstrup’s wrrnty obligtions do not pply in cse of incorrect mounting.
Plese note tht the following instlltion conditions must be obeyed:
- Pressure stge ULTRAFLOW®: PN16/PN25/PN40, see mrking. Flow sensor mrking does not
pply to enclosed ccessories.
- Pressure stge Kmstrup
sensor pir type DS: PN16
- Pressure stge Kmstrup
stinless steel pockets: PN25/PN40 - depending on type
At medium tempertures bove 90 °C we recommend the use of flnge meters s well s wll
mounting of MULTICAL® 602.
