MULTICAL® 801
3.2 Mounting of ULTRAFLOW® ≤ DN125
ULTRAFLOW® cn be mounted
verticlly, horizontlly or t n ngle.
90°
90°
ULTRAFLOW® my be turned up to
±45° round the pipe xis.
The electronics/plstic box must
be plced on the side (t horizontl
mounting).
Mx. 45°
Mx. 45°
The ULTRAFLOW® housing must
not be mounted fcing upwrds or
downwrds.
3.2.1 Humidity and condensation
When instlled in humid environments ULTRAFLOW® must be turned 45°
round the pipe xis s shown below.
If condenstion is likely, e.g. in
cooling systems, n ULTRAFLOW®
which is protected ginst
condenstion must be used.
45°
3.3 Mounting of ULTRAFLOW® 54 ≥ DN150
See instlltion instructions No. 5512-887.
