3.1 Mounting of couplings and short direct sensor mounted in
ULTRAFLOW® flow part
The short direct sensor from
Kmstrup cn only be mounted
in PN16 instlltions. The blind plug
mounted in the ULTRAFLOW® cn be
used in connection with both PN16
nd PN25.
The flow meter cn be used in both
PN16 nd PN25 nd cn be supplied
mrked either PN16 or PN25 s
desired.
Fittings, if supplied, cn only
be used for PN16. For PN25
instlltions, fittings suitble for
PN25 should be used.
In connection with G¾x110 mm and
G1x110 mm it shall be checked that
the thread run-out is sufficient. See
the figures to the right.
Tightening
pp. 4 Nm
Gsket
10 mm
Type 65-5-XXAX-XXX
Gsket
Tightening
pp. 4 Nm
12 mm
Type 65-5-XXHX-XXX
Couplings nd gskets re mounted s shown in the bove figures.
Stright inlet: ULTRAFLOW® requires neither stright inlet nor stright outlet
to meet the Mesuring Instruments Directive (MID) 2004/22/ EC nd EN
1434:2007. A stright inlet section will only be necessry in cse of hevy
flow disturbnces before the meter. We recommend to follow the guidelines
of CEN CR 13582.
