Kamstrup ULTRAFLOW 54 Installation Guide

9Kamstrup A/S • 5512887_B2_GB_09.2015
ULTRAFLOW® 54 · DN150-300
2 Electricl connection
2.1 Connection to clcultor
Signl cble length:
ULTRAFLOW® 54 DN150-300
output module
MULTICAL® 602/801
2-wire connection 3-wire connection
Y=1 N/A < 10 m
Y=2 < 100 m * < 25 m
Y=3 N/A < 25 m
* MULTICAL® 602 must hve sensor connection type D nd externl 24 VDC supply.
Tble 1
2.1.1 ULTRAFLOW® 54 nd MULTICAL®, glvniclly coupled
If ULTRAFLOW® 54 nd MULTICAL® re connected vi output module (Y=1), ULTRAFLOW® 54 is
glvniclly coupled with the MULTICAL® clcultor nd is powered by the clcultor vi the three-
wire signl cble (cble length up to 10 m).
Note: It is not permitted to mount  supply module or bttery in ULTRAFLOW® 54.
ULTRAFLOW® 54
®
MULTICAL®
11
®
11 GND (Blue)
9
®
9 +3.6 V (Red)
10
®
10
(Yellow)
Tble 2
2.1.2 ULTRAFLOW® 54 nd MULTICAL®, glvniclly seprted
If ULTRAFLOW® 54 nd MULTICAL® re connected vi output module (Y=2 or 3) ULTRAFLOW® 54 is
glvniclly seprted from MULTICAL®.
Note: Flow info cnnot be red.
Digrm 1 – Three-wire connection, MULTICAL® 602/801 vi output module (Y=2).
Cble length up to 25 metres.
