Rev. 1.00

20801-EDEBDA0232-4716-1_EN

KBR multicomp F144-NC-1V1C6DO6RO-2 Description of the display window









7 Description of the individual display win-

dows

7.1 Initialization window:

This is displayed after attaching the supply voltage to the controller.

Note

During the initialization period, please do not press any sensor buttons;

they are adjusted automatically to ensure correct operation.

7.2 Commissioning window if no stage power is programmed:

At the initial startup of the multicomp F144-1V1C6DO6RO-2, the Commis-

sioning menu is displayed as the start screen (after the initialization phase)

once you have set up the supply voltage.

This menu is used for the initial startup of the controller, where all necessary

settings can be made.

If a controller that is already integrated into a KBR compensation system by

default should be used, only the parameters of the current transformer

have to be con gured.

Select submenus by pressing

.
