KBR multicomp F144-NC-1V1C6DO6RO-2 User Manual

Rev. 1.00
20801-EDEBDA0232-4716-1_EN
38
KBR multicomp F144-NC-1V1C6DO6RO-2 Con gurable parameters
10 Setting range of the
con gurable parameters:
Primary voltage 1 V to 39999 V Ph-Ph
Secondary voltage 1 V to 999 V Ph-Ph
Primary current 1 A to 39999 A
Secondary current 1 and 5 A
Rot. eld U L1N, L2N, L3N, L12, L23, L31
Rot. eld I L1, L2, L3, -L1, -L2, -L3
Consumption target CosPhi ind. 0.80 to cap. 0.80
Recovery target CosPhi ind. 1.0 (cannot be con gured)
PFC too small alarm CosPhi ind. 0.70 to 1.0
Attenuation coe cient current 0 to 9
Attenuation coe cient voltage 0 to 9
Attenuation coe cient Qmiss 0 to 9
Thyristor stage idle time 20 to 9999 milliseconds
Contactor stage idle time 0 to 300 seconds
Alarm relay time 0 to 3000 seconds
Hysteresis connection 70 to 150 %
Hysteresis disconnection 70 to 150 %
Thyristor stage switching interval 50 to 9999 milliseconds
Contactor stage switching interval 0 to 10 seconds
Contactor operating cycle limit 0 to 999999
Stage power 0 to 999.9 kvar
Thyristor stage discharge time 20 to 9999 milliseconds
Contactor stage discharge time 0 to 900 seconds
Stage switching mode automatic, manual o , manual on
Stage power monitoring can be deactivated
Harmonics monitoring can be deactivated (0%)
