KBR multicomp F144-NC-1V1C6DO6RO-2 Technical data
11 Technical data
11.1 Measuring and display values
Voltage RMS value of a
measuring interval
Phase - 0 or phase - phase,
depending on programming
Units [V; kV;] display is switched automatically
Display range 0.00 kV to 99.9 kV
Measuring range 30 ... 690 ... 790 V
Current (apparent
current)
RMS value of a
measuring interval
Actual value per phase
Units [A; kA] display is switched automatically
Display range 0.00 A to 999 kA
Measuring range 0.015 ... 5 ... 6 A
Frequency Power frequency
measurement
f
Network
Units [Hz]
Measuring range 40.....70 Hz
Apparent power Calculation S
total
, three-phase
Units kVA
Measuring range 0.0 VA to 9999.9 kVA
Active power Calculation P
total
; three-phase
Units kW
Measuring range 0.0 W to 9999.9 kW
Reactive power Calculation
—> ind. & cap.
Q
total
; Q
miss
; distinction between ind./cap.
Units kvar
Display range 0.0 var to 9999.9 kvar
Power factor Calculation —> ind.
& cap.
CosPhi; distinction between ind./cap.
CosPhi in display
Display range CosPhi 0.10 ind. <—1 —>0.10 cap.
Harmonics Distortion factor
(THD) for voltage
Voltage: THD-U
Partial distortion
factors
3.; 5.; 7.; 9.; 11.; 13.; Voltage harmonics
Units [%]
Measuring range 0.00% to 100%
