KBR multicomp F144-NC-1V1C6DO6RO-2 Control and display panel
Note
Limit for overvoltage switch-o = rated voltage + 10% (taking into account the
measuring voltage ratio). The value of 10% cannot be changed and serves to
protect the compensation system. The reset hysteresis is 1 % of the rated volt-
age.
In the event of an error, the compensation stages are switched o
and “overvoltage” is displayed.
2 Control and display panel
multicomp F144-1V1C6DO6RO
Operating elements:
1 LCD displaying the current status and user prompts
2 Number of possible controller output lines
3 Two sensor buttons for parameter con guration
4 Two sensor buttons for menu selection
1
2
3 4
