KBR multicomp F144-NC-1V1C6DO6RO-2 User Manual

Rev. 1.00
20801-EDEBDA0232-4716-1_EN
11
KBR multicomp F144-NC-1V1C6DO6RO-2Control and display panel
General notes on operating the sensor buttons:
Button
 Start input for con guration and reset
Button
 Change values during con guration
Button
 Navigation though submenus
Button
 Navigation through main menus and save button
during con guration
Button combinations:
Button
 and  Delete accumulated values and perform reset
Default controller settings after reset:
Commissioning menu
 Password: no password (9999, meaning all functions
are accessible)
 Main transformer current: Primary current 1000 A
Secondary current 5 A
 Target CosPhi consumption: 0.95 inductive
 Measuring voltage: Primary voltage 400 V Ph-Ph
Secondary voltage 400 V Ph-Ph
 Thyristor discharge time: 20 milliseconds
 Contactor discharge time: 180 seconds
 Max. stage power per switching operation 0 kvar
 Rotary  eld U: L1-N
 Rotary  eld I: L1
 Stage power: not set
Switching performance menu
 Hysteresis connection: 100% of lowest stage power
 Hysteresis disconnection: 100% of lowest stage power
 Alarm delay: 20 minutes (1200 seconds)
 Thyristor idle time: 20 milliseconds
 Contactor idle time: 30 seconds
 Thyristor switching interval: 50 milliseconds
 Contactor switching interval: 8 seconds
 Alarm CosPhi: 0.92 inductive
 Attenuation coe cient Q
miss
: 0
 Attenuation coe cient for voltage: 0
 Attenuation coe cient for current: 0
