KBR multicomp F144-NC-1V1C6DO6RO-2Technical data
11.9 Mechanical data
Switchboard
installation
Housing dimensions 144 x 144 x 60 mm (H x W x D),
Assembly cut-out 138 x 138 mm
Protection type Front IP51 (with optionally available front
door max. IP54), terminals IP20
Weight Approx. 650g
11.10 Standards and miscellaneous
Ambient con-
ditions
Standards DIN EN 60721-3-3/A2: 1997-07; 3K5+3Z11;
(IEC721-3-3; 3K5+3Z11)
Operating tempera-
ture
-5 °C ….+55 °C
Humidity 5 % ….... 95 %
Storage temperature -25 °C ….+70 °C
Operating altitude up to max. 2000 m above sea level
Electrical safety Standards DIN EN 61010-1/A2: Aug. 2002; (IEC1010-1/
A2)
Protection class I, in accordance with DIN EN 61010-/A2: Aug.
2002
Overvoltage category CAT III: UPH-PH up to 400 V
Protection type IP20 in accordance with DIN EN 40050 part
9: 1993-05
Electromagnetic com-
patibility
DIN EN 61000-6-3: 2005-6; (IEC 61000-6-3)
DIN EN 61000-6-2: 2005; (IEC 61000-6-2)
Password
protection
4-digit code Deleting and programming parameters
on the device is not enabled if password
protection is active.
