Rev. 1.00
20801-EDEBDA0232-4716-1_EN
26
KBR multicomp F144-NC-1V1C6DO6RO-2 Description of the display window
The missing compensation power is displayed up to a maximum value of
9999.9 kvar.
If the value exceeds this limit, ----.- kvar is displayed
Power frequency in Hertz
THD (Harm. U total) in %, decisive for setting the THD limit (Extras menu, THD
limit submenu)
The rmware version of the controller, e.g. V 1.00R001, is important for sup-
port cases, as it can be used to deduce possible changes made to the device
rmware.
7.4 Stage state window:
Select submenus by pressing .
In the submenus of this window, it is displayed whether or not the capacitor
stages connected are working in automatic operation, or if they are switched
on or o permanently. The individual capacitor stages can be selected by press-
ing
.
By pressing
to start entering values, to make changes and to
save them, you can change the stage state from (Automatic) to
(switched o permanently) or (switched on permanently).
Note
Capacitor stages permanently switched on or o are not available to calculate
the optimizing automatic operation.
