KBR multicomp F144-NC-1V1C6DO6RO-2 Technical data
12 Selection of lines and fuses
C power (400 V) Q
(kvar)
Current consumption
I (A) per phase
Supply line
Cu (mm²)
Fuse (slow-blow)
3 x I (A)
0.5
1
1.5
2
2.5
3
4
5
6
7.5
10
12.5
15
16.7
20
25
30
33.3
35
40
45
50
60
70
75
80
90
100
120
125
150
180
200
250
300
350
400
450
500
0.72
1.44
2.16
2.88
3.60
4.32
5.76
7.20
8.64
10.80
14.40
18.00
21.60
24.00
28.80
36.00
43.20
48.00
50.40
57.60
64.80
72.00
86.40
100.80
108.00
115.10
129.60
144.00
172.80
180.00
216.00
259.20
288.00
360.00
432.00
504.00
576.00
648.00
720.00
4 x 1.5
4 x 1.5
4 x 1.5
4 x 1.5
4 x 1.5
4 x 1.5
4 x 1.5
4 x 2.5
4 x 2.5
4 x 2.5
4 x 2.5
4 x 6
4 x 10
4 x 10
4 x 10
4 x 16
4 x 16
4 x 16
4 x 25
4 x 25
3 x 35/16
3 x 50/25
3 x 50/25
3 x 70/35
3 x 70/35
3 x 95/50
3 x 95/50
3 x 95/50
3 x 120/70
3 x 120/70
3 x 150/70
3 x 240/120
3 x 240/120
2 x 3 x 150/70
2 x 3 x 185/95
2 x 3 x 240/120
2 x 3 x 240/120
4 x 3 x 120/70
4 x 3 x 150/70
10
10
10
10
10
10
10
16
16
16
25
35
35
35
50
63
80
80
80
100
100
125
125
160
160
200
200
250
250
250
315
400
400
500
630
2 x 400
2 x 400
2 x 500
2 x 500
