KBR multicomp F144-NC-1V1C6DO6RO-2 User Manual

Rev. 1.00
20801-EDEBDA0232-4716-1_EN
12
KBR multicomp F144-NC-1V1C6DO6RO-2 Control and display panel
Extras menu
 THD limit: 8 %
 Harmonics monitoring: Activated by set limit
 Contactor stage operating cycle limit: 80000
 Operating cycle count: Activated by set limit
 Scanning frequency: Automatic
 Stage power monitoring: Deactivated
 Contrast setting: 4
 Low-load limit: 15 mA
 Low-load delay: 60 minutes
Other
 Recovery target CosPhi: 1.00, cannot be changed
 Stage switching mode: Automatic
The controls in the compensation systems are preset.
The following need to be checked or set:
target CosPhi in accordance with the energy supplier regulations
(for kVA tari CosPhi = 1)
 Primary current and secondary current in accordance with input current transformer.
 If required, voltage transformer ratio
