KBR multicomp F144-NC-1V1C6DO6RO-2 Description of the display window
If the stage power limit is set lower than the value of the largest existing stage,
but larger than or equal to “0”, the controller automatically uses the largest
capacitor stage available.
Con guring the capacitor stages:
There are two ways of con guring the capacitor stages. The stages can be con-
gured manually or using the auto con guration mode.
It is important to set the stage power correctly. The stage power can be looked
up on the nameplate of the stage or the circuit diagram and then programmed
manually. In this case, skip the menu item "Activate learning mode" and indi-
vidually enter the power value for each stage.
Note
If the menu item "Activate learning mode" cannot be selected, you have to
verify that there is measuring voltage at the controller. If this is not the case, the
menu item is automatically disabled.
If you want to activate the learning mode, you have to make sure that all previ-
ous submenu parameters have been set correctly.
The learning mode is activated by pressing
. Change to by pressing
and con rm with
.
After starting the learning mode, ashes and the remaining time
until the end of the learning mode is displayed.
Note
The auto con guration mode then automatically sets the stage power. You
have to ensure that the current ow though the main current transformer is not
in uenced by switching consumers on or o . Check the stage power deter-
mined after each time the learning process is performed.
