KEB COMBIVERT F4-C Applications Manual

6 3
KEB COMBIVERT F4-C
14
Name: Basis
28.01.98
Chapter Section
Page Date
© KEB Antriebstechnik, 1997
All Rights reserved
Functional Description Digital In- and Outputs
Param. Adr.
min
max
default
ENTER
PROG.
R/W
Step
do.2 2A02h ✔✔✔ 03512-
do.3 2A03h ✔✔✔ 035120-
do.4 2A04h ✔✔✔ 03510-
do.9 2A09h ✔✔✔ 0 15 1 1 bit-coded
do.10 2A0Ah ✔✔✔ 0 15 1 2 bit-coded
do.11 2A0Bh ✔✔✔ 0 15 1 3 bit-coded
do.13 2A0Dh ✔✔✔ 0 15 1 0 bit-coded
do.14 2A0Eh ✔✔✔ 0 15 1 0 bit-coded
do.15 2A0Fh ✔✔✔ 0 15 1 0 bit-coded
do.16 2A10h ✔✔✔ 0 15 1 0 bit-coded
do.17 2A11h ✔✔✔ 0 15 1 9 bit-coded
do.18 2A12h ✔✔✔ 0 15 1 9 bit-coded
do.19 2A13h ✔✔✔ 0 15 1 9 bit-coded
do.21 2A15h ✔✔✔ 0 15 1 9 bit-coded
do.22 2A16h ✔✔✔ 0 15 1 9 bit-coded
do.23 2A17h ✔✔✔ 0 15 1 9 bit-coded
do.24 2A18h ✔✔✔ 0 15 1 9 bit-coded
do.25 2A19h ✔✔✔ 0 255 1 0 bit-coded
LE.0 2B00h ✔✔- 0,0 Hz 409,5875 Hz 0,0125 Hz 0,0 Hz -
LE.1 2B01h ✔✔- 0,0 Hz 409,5875 Hz 0,0125 Hz 4,0 Hz -
LE.2 2B02h ✔✔- 0,0 Hz 409,5875 Hz 0,0125 Hz 4,0 Hz -
LE.3 2B03h ✔✔- 0,0 Hz 409,5875 Hz 0,0125 Hz 50,0 Hz -
LE.8 2B08h ✔✔- 0 % 200 % 1 % 50 % -
LE.9 2B09h ✔✔- 0 % 200 % 1 % 100 % -
LE.10 2B0Ah ✔✔- 0 % 200 % 1 % 100 % -
LE.11 2B0Bh ✔✔- 0 % 200 % 1 % 100 % -
LE.16 2B10h ✔✔- 0,0 A 460 A 0,1 A 0,0 A -
LE.17 2B11h ✔✔- 0,0 A 460 A 0,1 A 0,0 A -
LE.18 2B12h ✔✔- 0,0 A 460 A 0,1 A 0,0 A -
LE.19 2B13h ✔✔- 0,0 A 460 A 0,1 A 0,0 A -
LE.24 2B18h ✔✔- 100 V LTK 1 V 250 V LTK: depend. on power circuit
LE.25 2B19h ✔✔- 100 V LTK 1 V 250 V LTK: depend. on power circuit
LE.26 2B1Ah ✔✔- 100 V LTK 1 V 250 V LTK: depend. on power circuit
do.0 2A00h ✔✔✔ 0 255 1 0 bit-coded
do.1 2A01h ✔✔✔ 035114-
