KEB COMBIVERT F4-C Applications Manual

13
ANTRIEBSTECHNIK
6
313
KEB COMBIVERT F4-C
Name: Basis
28.01.98
6
Section
Page
Date
© KEB Antriebstechnik, 1997
All Rights reserved
Chapter
Functional DescriptionDigital In- and Outputs
Param. Adr.
min
max
default
ENTER
PROG.
R/W
Step
Terminal Name Function Decimal value do.0, do.25 u. ru.15
X1.12 Out1 Transistor output 1
X1.1...3 Out2 Relay output 2
X1.21...23 Out3 Relay output 4
- - reserved -
- Out A Internal output 16
- Out B Internal output 32
- Out C Internal output 64
- Out D Internal output 128
6.3.19 Inverting of the
Outputs (do.0)
As shown in picure 6.3.18 with parameter do.0 the outputs can be inverted once
more after linkage. The parameter is bit-coded, i.e. according to following table the
value belonging to the output is to be entered, If several outputs shall be inverted,
add up the values.
6.3.20 Output Terminal
Status (ru.15)
The output terminal status indicates logic condition of digital outputs. It is irrelevant
whether the output is set based on conditions or through inverting. If an output is set
the corresponding value according to above table is shown. If several outputs are set
the sum of the decimal values is shown.
Example: Out1 and Out3 are set ➭ 1+4 = 5
6.3.21 Used Parameters
di.0 2900h ✔ -- 0 31 1 0 t
F
= (0...31+1)*4ms
di.1 2901h ✔ - ✔ PNP NPN 1 PNP -
di.2 2902h ✔ - ✔ 0 255 1 0 bit-coded
di.3 2903h ✔ -- 0 16 1 9 -
di.4 2904h ✔ -- 0 16 1 9 -
di.5 2905h ✔ -- 0 16 1 3 -
di.6 2906h ✔ -- 0 16 1 4 -
di.7 2907h ✔ -- 0 16 1 0 -
di.8 2908h ✔ -- 0 16 1 0 -
di.9 2909h ✔ -- 0 16 1 0 -
di.10 290Ah ✔ -- 0 16 1 0 -
di.14 290Eh ✔ - ✔ 0 255 1 0 bit-coded
di.15 290Fh ✔ - ✔ 0 255 1 0 bit-coded
di.16 2910h ✔ - ✔ 0 255 1 0 bit-coded
di.17 2911h ✔ - ✔ 0 255 1 0 bit-coded
di.18 2912h ✔ - ✔ 0 255 1 0 bit-coded
di.19 2913h ✔ - ✔ 0110-
di.20 2914h ✔ - ✔ 0 7 1 1 0: Run/Stop 1: For/Rev
di.21 2915h ✔ - - 0 2 1 0 0:Reset↓ 1:Reset↑ 2:no reset
