KEB COMBIVERT F4-C
Name: Basis
5
Section PageDate
© KEB Antriebstechnik, 1997
All Rights reserved
Chapter
20.03.98
Parameter
LE 34 OH Warning Level 2B22 √ - √ 0 100 1 70 degrees
LE 35 Timer Value 2B23 √ - √ 0,00 100,00 0,01 0,00 sec 6.3.11; 6.9.17
LE 36 Frequency Hysteresis 2B24 - - √ 0,0000 20,0000 0,0125 0,5000 Hz
LE 41 Timer A Level 1 2B29 √ - √ 0,00 300,00 0,01 0,00 sec / hour 6.1.13; 6.3.11; 6.9.18
LE 42 Timer A Level 2 2B2A √ - √ 0,00 300,00 0,01 0,00 sec / hour 6.9.18
LE 43 Timer A Level 3 2B2B √ - √ 0,00 300,00 0,01 0,00 sec / hour 6.9.18
LE 44 Timer A Level 4 2B2C √ - √ 0,00 300,00 0,01 0,00 sec / hour 6.9.18
LE 45 Timer A Reset Condition 2B2D - - √ 0 15 1 8192 - 6.9.18
LE 46 Timer A Inc Condition 2B2E - - √ 0 15 1 2047 - 6.9.17
LE 47 Timer A Resolution 2B2F - - √ 0 : 0,01 sec 1 : 0,01 h 1 0 : 0,01 sec - 6.9.17
LE 62 Percentage Level 1 2B3E √ - √ -400,0 400,0 0,1 0,0 % 6.3.11
LE 63 Percentage Level 2 2B3F √ - √ -400,0 400,0 0,1 0,0 %
LE 64 Percentage Level 3 2B40 √ - √ -400,0 400,0 0,1 0,0 %
LE 65 Percentage Level 4 2B41 √ - √ -400,0 400,0 0,1 0,0 % 6.3.11
LE 69 Analog Hysteresis 2B45 - - √ 0,0 20,0 0,1 2,0 % 6.3.11
In - Parameter Adr.
min
max
default
[?] see Page(s)
In 0 Inver ter Type 2C00 - - - table type plate - 6.1.15
In 1 Rated Inverter Current 2C01 - - - 0 370 0,1 LTK A 6.1.15
In 2 Max. Output Frequency 2C02 - - √ 0 409,5875 0,0125 409,5875 Hz 6.1.16
In 3 Max. Carrier Frequency 2C03 - - - 1 LTK 1 LTK kHz 6.1.16
In 4 Software Version 2C04 - - - 1 - 6.1.16
In 5 Software Date 2C05 - - - 0,1 - 6.1.16
In 6 Configfile No. 2C06 - - √ conf.no. conf.no. 1 conf.no. - 6.1.16
In 7 Serial No. (Date) 2C07 - - √ 0 65535 1 0 - 6.1.17
In 8 Serial No. (Counter) 2C08 - - √ 0 65535 1 0 - 6.1.17
In 9 Serial No. (AB-no. High) 2C09 - - √ 0 65535 1 0 - 6.1.17
In 10 Serial No. (AB-no. Low) 2C0A - - √ 0 65535 1 0 - 6.1.17
In 11 Cust. No. (High) 2C0B - - √ 0 65535 1 0 - 6.1.17
In 12 Cust. No. (Low) 2C0C - - √ 0 65535 1 0 - 6.1.17
In 13 QS No. 2C0D - - √ 0 255 1 0 - 6.1.17
In 15 REF Offset + 2C0F - - √ -32767 32767 1 0 - 6.1.17
In 16 REF Offset - 2C10 - - √ -32767 32767 1 0 - 6.1.17
In 17 REF Gain + 2C11 - - √ 0 32767 1 16384 - 6.1.17
In 18 REF Gain - 2C12 - - √ 0 32767 1 16384 - 6.1.17
In 19 REF2 0-10V Offset 2C13 - - √ -32767 32767 1 0 - 6.1.17
In 20 REF2 0-10V Gain 2C14 - - √ 0 32767 1 16384 - 6.1.17
In 21 REF2 0-20mA Offset 2C15 - - √ -32767 32767 1 0 - 6.1.17
In 22 REF2 0-20mA Gain 2C16 - - √ 0 32767 1 16384 - 6.1.17
In 23 REF2 4-20mA Offset 2C17 - - √ -32767 32767 1 820 - 6.1.17
In 24 REF2 4-20mA Gain 2C18 - - √ 0 32767 1 20480 - 6.1.17
In 40 Last Error 2C28 - - √ 0 63 1 0 - 6.1.17
In 41 Error Counter OC 2C29 - - √ 0 255 1 0 - 6.1.18
In 42 Error Counter OL 2C2A - - √ 0 255 1 0 - 6.1.18
In 43 Error Counter OP 2C2B - - √ 0 255 1 0 - 6.1.18
In 44 Error Counter OH 2C2C - - √ 0 255 1 0 - 6.1.18
In 45 Error Counter buS 2C2D - - √ 0 255 1 0 - 6.1.18
In 58 User Parameter 1 2C3A - - √ 0 32767 1 0 - 6.1.18
In 59 User Parameter 2 2C3B - - √ 0 32767 1 0 - 6.1.18
CP - Parameter Adr.
min
max
default
[?] see Page(s)
CP 0 Password Key / Bus 2600/2601 4.3.3; 4.4.3; 6.12.3
CP 1 User defined 3301 4.3.3; 6.12.4
CP 2 User defined 3302 4.3.3; 6.12.4
CP 3 User defined 3303 4.3.3; 6.12.4
CP 4 User defined 3304 4.3.3; 6.12.4
CP 5 User defined 3305 4.3.3; 6.12.4; 7.2.4
CP 6 User defined 3306 4.3.3; 6.12.4; 7.2.4
CP 7 User defined 3307 4.3.3; 6.12.4; 7.2.4
CP 8 User defined 3308 4.3.3; 6.12.4; 7.2.4
CP 9 User defined 3309 4.3.3; 6.12.4; 7.2.4
CP 10 User defined 330A 4.3.3; 6.12.4; 7.2.4
CP 11 User defined 330B 4.3.3; 6.12.4
CP 12 User defined 330C 4.3.3; 6.12.4
CP 13 User defined 330D 4.3.3; 6.12.4
CP 14 User defined 330E 4.3.3; 6.12.4
CP 15 User defined 330F 4.3.3; 6.12.4
CP 16 User defined 3310 4.3.3; 6.12.4
CP 17 User defined 3311 4.3.3; 6.12.4
CP 18 User defined 3312 4.3.3; 6.12.4
CP 19 User defined 3313 4.3.3; 6.12.4
CP 20 User defined 3314 4.3.3; 6.12.4
CP 21 User defined 3315 4.3.3; 6.12.4
CP 22 User defined 3316 4.3.3; 6.12.4
CP 23 User defined 3317 4.3.3; 6.12.4
CP 24 User defined 3318 4.3.3; 6.12.4
