6 1
Name: Basis
KEB COMBIVERT F4-C
12
09.04.99
© KEB Antriebstechnik, 1999
All Rights reserved
Functional Description
Chapter Section Page
Date
Operating and Appliance Displays
Adr.
min max
default
Adr.
min max
default
Adr.
min max
default
Adr.
min max
default
2011h
ru.17 Internal output status
1
-
-
150
With parameters do.1…do.4 switching conditions can be selected which serve as basis for the setting of the outputs.
This parameter indicates which of the selected switching conditions are met, before they are linked by the programmable
logic or inverted. According to following table a certain decimal value is given out for the parameters do.1…do.4. If
several of the switching conditions selected with these parameters are met, then the sum of the decimal values is
displayed.
Bit -No. Decimal value Output
0 1 switching condition 1 (do.1)
1 2 switching condition 2 (do.2)
2 4 switching condition 3 (do.3)
3 8 switching condition 4 (do.4)
2012h
ru.18 Active parameter set
1
-
-
70
The frequency inverter F4-C can fall back on 8 internal parameter sets (0-7). Through corresponding programming the
inverter can independently change parameter sets and is thus able to drive different operating modes. This parameter
shows the parameter set, with which the inverter is currently running and which can be edited by keyboard. Indepen-
dent of it another parameter set can be edited by bus.
2016h
ru.22 REF +/- display (terminal X1.8 and X1.9)
0,1
%
-
100-100
This parameters displays the percentual value of the signal at the analog input REF+/REF- (terminal X1.8/X1.9).
-10V...0...+10V = -100%...0...100%
2017h
ru.23 REF display (terminal X1.17)
0,1
%
-
100-100
This parameter displays the percentual value of the signal at the analog input REF (terminal X1.17). 100 % relate to the
final value of the signal source selected with An.6.
Example: 0...20mA = 0...100% or 4...20mA = 0...100% or 0...10V = 0...100%
