KEB COMBIVERT F4-C Applications Manual

6 1
Name: Basis
KEB COMBIVERT F4-C
18
09.04.99
© KEB Antriebstechnik, 1999
All Rights reserved
Functional Description
Chapter Section Page
Date
Operating and Appliance Displays
Adr.
min max
default
1
-
0
655350
Adr.
min max
default
1
-
s.o.
32767-32767 (0)
Adr.
min max
default
2C28h
1
-
-
630
s.above
The serial number and the customer number identify the inverter. The QS-number contains internal production information.
In. 7 Serial number / date 2C07h
In. 8 Serial number / counter 2C08h
In. 9 Serial number / Ackn.-No. high 2C09h
In.10 Serial number / Ackn.-No. low 2C0Ah
In.11 Customer number / high 2C0Bh
In.12 Customer number / low 2C0Ch
In.13 QS-number 2C0Dh
s.above
These parameters display the result of the automatic adjustment of the analog inputs and are intended for the service
technicians.
In.15 REF Offset+ 2C0Fh 0
In.16 REF Offset- 2C10h 0
In.17 REF Gain+ 2C11h 16384
In.18 REF Gain- 2C12h 16384
In.19 REF2 / 0...10V Offset 2C13h 0
In.20 REF2 / 0...10V Gain 2C14h 16384
In.21 REF2 / 0...20mA Offset 2C15h 0
In.22 REF2 / 0...20mA Gain 2C16h 16384
In.23 REF2 / 4...20mA Offset 2C17h 820
In.24 REF2 / 4...20mA Gain 2C18h 20480
In.40 displays the last error that occurred, E.UP is not stored. You find a description of the error messages at parameter
ru.0.
In.40 Last error
