KEB COMBIVERT F5-G / B
Name: Basis
14.06.02
Section PageDate
© KEB Antriebstechnik, 2002
All Rights reserved
Chapter
Parameter Adr. Control Properties min. max. Step default [?] see on Page
5
op56 mot.poti inc. input sel. 0338 B g G M S A - - E - 0 4095 1 0 - 6.3.8, 6.9.8
op57 mot.poti dec. input sel. 0339 B g G M S A - - E - 0 4095 1 0 - 6.9.8, 6.3.8
op58 mot.poti reset inp. sel. 033A B g G M S A - - E - 0 4095 1 0 - 6.9.8, 6.3.8
op59 motorpoti inc/dec time 033B B g G M S A - - - - 0,00 50000,00 0,01 66,00 s 6.9.8
op60 dir. forward input sel. 03 3C B g G M S A - - E - 0 4095 1 4 - 6.3.8, 6.4.7
op61 dir. reverse input sel. 033D B g G M S A - - E - 0 4095 1 8 - 6.3.8, 6.4.7
op62 acc/dec time factor 033E B g G M S A - - E - 0 4 1 0 - 6.4.13
pn 0 auto retry UP 0400 B g G M S A - - - - 0 1 1 1 - 6.7.7
pn 1 auto retry OP 0401 B g G M S A - - - - 0 1 1 0 - 6.7.7
pn 2 auto retry OC 0402 B g G M S A - - - - 0 1 1 0 - 6.7.7
pn 3 E. EF stopping mode 0403 B g G M S A - - - - 0 6 1 0 - 6.7.10
pn 4 ext. fault input select 0404 B g G M S A - - E - 0 4095 1 64 - 6.7.9, 6.3.8
pn 5 E.buS stopping mode 0405 B g G M S A - - - - 0 6 1 6 - 6.7.10, 11.2.3
pn 6 watchdog time 0406 B g G M S A - - E - 0,00:off 10,00 0,01 0,00:off s 6.7.10, 11.2.3
pn 8 warning OL stop. mode 0408 B g G M S A - - - - 0 6 1 6 - 6.7.11, 6.3.15
pn 9 OL warning level 04 09 B g G M S A - - - - 0 100 1 80 % 6.7.10
pn10 warning OH stop. mode 040A B g G M S A - - - - 0 6 1 6 - 6.7.11, 6.3.15
pn11 OH warning level 040B B g G M S A - - - - 0 90 1 70 °C 6.7.11
pn12 warning dOH stop. mode 040C B g G -------0 7 1 7 - 6.7.11, 6.3.15, 6.7.18
pn13 E.dOH delay time 040D B g G -------0 120 1 10 s 6.7.11, 6.7.18
pn14 warning OH2 stop. mode 040E B g G M S A - - - - 0 6 1 6 - 6.7.12, 6.7.17, 6.3.15
pn16 warning OHI stop. mode 04 10 B g G M S A - - - - 0 7 1 7 - 6.7.12, 6.3.16
pn17 E.OHI delay time 04 11 B g G M S A - - - - 0 120 1 0 s 6.7.12
pn18 E.Set stopping mode 0412 B g G M S A - - - - 0 6 1 0 - 6.7.12
pn19 stall mode 0413 - - G M - - - P E - 0 255 1 0 - 6.7.5
pn19 stall mode 0413 B g - - - A - P E - 0 127 1 0 - 6.7.5
pn20 stall level 0414 B g G M - A - P - - 0 200 1 200:off % 6.7.6
pn21 stall acc/dec time 0415 B g G M - A - P - - 0 300,00 0,01 2,00 s 6.7.6
pn22 LAD stop function 0416 B g G M S A - P E - 0 7 1 1 / 0 - 6.7.3
pn23 LAD stop input selection 0417 B g G M S A - - E - 0 4095 1 0 - 6.7.3, 6.3.8
pn24 LAD load level 0418 B g G M S A - P - - 0 200 1 140 % 6.7.3
pn25 LD voltage 0419 B g G M S A - P - - 200 800 1 375 / 720 V 6.7.3
pn26 speed search condition 041A B g G M - A - P E - 0 15 1 8 - 6.7.7
pn27 speed search mode 041B B g G M - A - - E - 0 127 1 0/88 - 6.7.7
pn28 DC braking mode 041C B g G M - A - P E - 0 9 1 7 - 6.9.4
pn29 DC brake input selection 041D B g G M - A - - E - 0 4095 1 128 - 6.9.4, 6.3.8
pn30 DC braking time 04 1E B g G M - A - P - - 0,00 100,00 0,01 10,00 s 6.9.3
pn31 DC braking max. voltage 041F B g G M - A - P - - 0,0 25,5 0,1 25,5 % 6.9.3
pn32 DC braking start freq. 0420 B g G ----P-V0 400 0,0125 4 Hz 6.9.3
pn34 brake control mode 0422 B g G M S A - P E - 0 4 1 0 - 6.9.16
pn35 premagnetizing time 04 23 B g G M S A - P - - 0,00 100,00 0,01 0,25 s 6.9.15
pn36 brake release time 0424 B g G M S A - P - - 0,00 100,00 0,01 0,25 s 6.9.15
pn37 brake ctrl. start ref. 0425 B g G ----P-V-20 20 0,0125 0 Hz 6.9.17
pn39 brake delay time 0427 B g G M S A - P - - 0,00 100,00 0,01 0,25 s 6.9.15
pn40 brake closing time 04 28 B g G M S A - P - - 0,00 100,00 0,01 0,25 s 6.9.15
pn41 brake ctrl. stop ref. 0429 B g G M S A - P - V -20 20 0,0125 0 Hz 6.9.17
pn41 brake ctrl. stop ref. 0429 B g G M S A - P - V -600 600 0,125 0 rpm 6.9.17
pn43 min. load brake ctrl. 042B B g G M S A - P - - 0 100 1 0 % 6.9.16
pn44 power off mode 042C B g G M S A - - E - 0 511 1 0 - 6.9.19, 6.9.20, 6.9.23
pn45 power off start voltage 042D B g G M S A - - - - 200 800 1 290 / 500 V 6.9.20, 6.9.21
pn46 power off auto st. level 042E B g G M S A - - - - 50 90 1 80 % 6.9.20, 6.9.21
pn47 power off brake torque 042F B g G - - A - - - - 0,0 100,0 0,1 0,0 % 6.9.21
pn48 power off restart level 0430 B g G ------V0 400 0,0125 0 Hz 6.9.22
pn50 power off ref. DC volt. 0432 B g G - - A - - - - 200 800 1 290 / 500 V 6.9.21
pn51 power off KP DC volt. 0433 B g G M - A - - - - 0 32767 1 128 - 6.9.22
pn52 power off restart delay 0434 B g G M S A - - - - 0,00 100,00 0,01 0,00 s 6.9.23
pn53 power off KP act.curr. 0435 B g G - - A - - - - 0 32767 1 50 - 6.9.22
pn54 power off KI act.curr. 0436 B g G - - A - - - - 0 32767 1 50 - 6.9.22
pn55 power off KD act.curr. 0437 B g G - - A - - - - 0 32767 1 0 - 6.9.22
pn56 power off jump factor 04 38 B g G - - A - - - - 0 800 1 100 % 6.9.20
pn57 power off KI DC volt. 0439 - - G M - A - - - - 0 32767 1 5 - 6.9.22
pn58 quick stop mode 043A B g G - - A - - E - 0 3 1 0 - 6.7.13
pn59 quick stop level 04 3B B g G - - A - - - - 0 200 1 200 % 6.7.13
pn60 quick stop acc/dec time 043C B g G M S A - - - - 0 300,00 0,01 2,00 s 6.7.13
pn62 dOH warning level 043E - - G M S A - - - - 0 200 1 100 °C 6.7.11
pn63 positioning delay 043F B g G - - A - P - - -0,02 327,67 0,01 -0,01 s 6.9.31
pn64 set GTR7 input selection 0440 - - G M S A - - E - 0 4095 1 0 - 6.7.19, 6.3.8
pn65 special functions 0441 - - G M S A - - - - 0 7 1 0 - 6.7.20, 6.7.19, 6.7.9
ru 0 inverter state 02 00 B g G M S A R - - - 0 255 1 0 - 6.1.6
ru 1 set value display 0201 B g G - - - R - - V -400 400 0,0125 0 Hz 6.1.6, 6.9.3
ru 2 ramp output display 0202 B g G - - - R - - V -400 400 0,0125 0 Hz 6.1.6
ru 3 actual frequency display 0203 B g G M S A R - - V -400 400 0,0125 0 Hz 6.1.6
ru 4 encoder 1 frequency 0204 - - G - - A R - - V -400 400 0,0125 0 Hz
ru 5 encoder 2 frequency 0205 - - G - - A R - - V -400 400 0,0125 0 Hz
ru 6 calculated act. freq. 0206 - - G - - A R - - V -400 400 0,0125 0 Hz
ru 7 actual value display 0207 - - G - - - R - - V -400 400 0,0125 0 Hz 6.1.7
ru 9 encoder 1 speed 02 09 - - G - - - R - - V -32000 32000 1 0 rpm 6.1.7
