Page 7.4 - 12 COMBIVERT F5-A, -E, -H © KEB, 2012-10
Setpoint, rotation- and ramp setting
Step value rotation source (oP.18)
The rotation source is determined with oP.18 atactive xed value . The function and the value range correspond
to oP.1.
oP.18: Step value rotation source
Value Function
0 digital via oP.2; setpoint 0-limited
1 digital via oP.2; setpoint absolute
2 Terminal block F/R; setpoint 0-limited
3 Terminal block F/R; setpoint absolute
4 Terminal block Run/Stop; setpoint 0-limited
5 Terminal block Run/Stop; setpoint absolute
6 setpoint-dependent with LS-recognition
7 setpoint-dependent without LS-recognition
8 Control word SY.50; 0-limited
9 Control word SY.50; 0-absolute
10 Setpoint + control word (SY.50) R/S
11
Setpoint + control word (Sy.50) run / stop without deceleration ramp
Step value input selection 1 and 2 (oP.19; oP.20)
See chapter 7.3.1 "digital inputs".
Step value 1...3 (oP.21, oP.22, oP.23)
The three step values oP.21...23 are set-programmable and can be adjusted in the range of -4000...4000
rpm.
