Operating and appliance data
7.1.2 Overview of the In-Parameters
The In- (Information) parameter group contains data and information on the identication of the hardware and
software as well as on the type and number of the errors that occurred. Following parameters are available:
In.00 inverter type
In.01 rated Inverter current
In.03 max. carrier frequency
In.04 rated carrier frequency
In.06 Software version
In.07 Software date
In.10 serial no. (date)
In. 11 serial no. (count)
In.12 serial no. (AB-no. high)
In.13 serial no. (AB-no. low)
In.14 customer no. (high)
In.15 customer no. (low)
In.16 QS no.
In. 17 Temperature mode
In.22 user parameter 1
In.23 user parameter 2
In. 24 Last error
In. 25 Error Assistance
In.26 E.OC error counter
In.27 E.OL error counter
In.28 E.OP error counter
In.29 E.OH error counter
In.30 E.OHI error counter
In.31 KEB Hiperface
In.32 Interface software date
7.1.3 Overview of the Sy-Parameters
The Sy- (system) parameter group contains system specic parameters. Following parameters are available:
SY.01 Watchdog cycle SY.44 Status word long
Sy.02 inverter identier SY.50 Control word low
Sy.03 Power unit code Sy. 51 Status word low
Sy.06 inverter address SY.52 Set speed value
Sy.07 baud rate ext. bus SY.53 actual speed display
SY.08 bus synchron time Sy.56 Start display address
Sy.09 HSP5 watchdog time
Sy.11 baud rate int. bus
SY.32 Scope timer
SY.41 Control word high
SY.42 Status word high
SY.43 Control word long
