Speed measurement
© KEB, 2012-10 COMBIVERT F5-A, -E, -H Page 7.11 - 13
7
Encoder trigger (Ec.07, Ec.17)
Value Evaluation of the encoder signals
0 1-fold (for initiator: evaluation of positive edges only) (2
0
)
1 2-fold (for initiator: evaluation of positive and negative edge)(2
1
)
2 4-fold (for incremental encoder) (2
2
) default
3 8-fold (23)
4 16-fold (24)
5 32-fold (25)
6 64-fold (26)
... ...
13 8192-fold (213)
Position value for channel 2 via parameter (Ec.28)
An encoder is connected to the master control. The position value is written to parameter Ec.28 via bus.
Rotary encoder: The control detects the whole revolutions and outputs a continuous position value to
Ec.28
Linear encoder: The controller detects the position value and outputs it toEc.28
Adjustment:
Ec.10 = 30 = „Position via Ec.28“. Independent of connection to channel 2.
Increments per revolution Ec.11 (128….16384, default 1024 inc)
Multiturn resolution Ec.21 ( 32….32, default 32 )
Resolution Ec.17 ( 2….9, default 9)
Position format:
The position value in a range of -2^31….2^31.1 is described in Ec.28.
The display standardization can not be changed with Ec.41. The overow detection after power-on is not
supported!
