KEB COMBIVERT F5-H User Manual

Protective functions
© KEB, 2012-10 COMBIVERT F5-A, -E, -H Page 7.13 - 33
7
3, 4
Behaviour on reaching
standstill
0: Mod. on, no restart
Status "78: power-off function active"
(POFF), modulation on, reset required
8: Mod. on, restart
Status "78: Power-off function active"
(POFF), modulation on, restart on
power recovery after Pn.52 "power off
restart delay"
16: PLS, no restart
Status "84: no direction of rotation after
power off" (PLS), modulation off, reset
required
24: reserved reserved
5 Power off mode
0: act. start voltage
Start according to the setting of bit 1
32: dig. input of Pn.49 Start via digital input
6, 7
Voltage setpoint selection
(not for vector controlled
DSM)
0: Starting voltage
Bridging of mains gaps.
Restart on power recovery, as long as
the initial speed is not lower than Pn.48
"power off restart level".
64: Voltage setpoint Pn.50
(only v/f-characteristic)
Emergency stop without braking mo-
dule
Restart possible only on reaching
standstill.
128: Voltage setpoint Pn.50,
if output speed < Pn.48
(only v/f-characteristic)
Bridging of mains gaps.
Restart on power recovery above
Pn.48 "power off restart level".
Setpoint increase from initial voltage to
voltage setpoint below Pn.48.
192: Brake torque (Pn.47)
Emergency stop with braking module
Restart possible only on reaching
standstill.
8
Voltage stabilization at po-
wer off (only v/f-char.)
0: on
Voltage stabilization during power off =
uF.09
256: off
Voltage stabilization during power off
deactivated
9
Power Off: Status = error,
if no restart after system
recovery
0: no error
The status changes to error as soon
as the restart value (Pn.48) is decrea-
sed at active power off function or the
maximum time for restart (Pn.96) is
elapsed.
This applies to SY. 51 bit 1, SY. 44 bit
1, SY. 79 bit 3 and switching conditions
do.00-07 = 3-5.
The inverter status (ru.00) does not
change, but the error LED ashes.
512: Error, if no restart
Tripping of power off
The power-off function starts when the DC-link voltage drops below a certain value (start voltage). The start
voltage can be set automatically or manually depending on Pn.44 Bit 1.
Starting voltage (Pn.45)
The starting voltage can be preset with Pn.45 in the range of 200...1200 volt at manual setting. The adjusted
starting voltage must be at least 50V over the UP-threshold for safe operation (UP: 200V class = 216V DC;
