Selection of Operating Mode
This operating instruction is not valid for the G mode (V/f - characteristic open-loop mode, because the dis-
play is scaled in Hz, not in rpm). I.e. this instruction is not valid for controller types, which selects the G-mode
(F5-G / xxxHz).
Attention:
If a download list is downloaded to an inverter with another controller type, or if the COMBIVIS Cong-File is
used for another controller type some parameters (e.g. set speed, speed limits, etc..) are not correctly displa-
yed.
COMBIVIS recognizes the use of inappropriate lists and select the correct cong le automatically. Unintended
settings and wrong displays can occur if the warning messages are ignored.
The standardisation of some parameters is depending on the speed range of the control type.
Stan-
dard
Speed range Resolution Parameter
1
500...32000 1 rpm
SY.52, SY.53, SY.5464000 2 rpm
128000 4 rpm
2
500 1Nm
dr.27, dr.33, dr.40, dr.42, dr.44, dr.46
4000...128000 0.1 Nm
3
500
4000...64000
128000
0.125 rpm
1 rpm
2 rpm
dr.01, dr.17, dr.18, dr.24, dr.39, dr.41, dr.43, dr.45, dr.47
cS.11, cS.12
Ec.25
nn.02, nn.03
dS.19
4
500
4000
8000
16000
32000
64000
128000
0.015625 rpm
0.125 rpm
0.25 rpm
0.5 rpm
1 rpm
2 rpm
4 rpm
Sy.45
ru.01, ru.02, ru.06, ru.07, ru.09, ru.10, ru.63, ru.79, ru.85,
ru.86, ru.89
op.03, op.06, op.07, op.10, op.11, op.14, op.15, op.21, op.22,
op.23, op.40, op.41, op.64, op.65, op.66, op.67, op.68
Pn.32, Pn.37, Pn.41, Pn.48
dS.21
Le.16
cS.04
PS.08, PS.09, PS.21, PS.22, PS.25
nn.08
5
500 0.0015625 Hz
ru.03
uF.00, uF.02
4000 0.0125 Hz
8000 0.025 Hz
16000 0.05 Hz
32000 0.1 Hz
64000 0.2 Hz
128000 0.4 Hz
Some parameters (ramp adjustments) have reference values, which are depending on the selected speed
range (500, 4000, 8000, 16000, 32000, 64000, 128000 rpm.
