Page 11.1 - 6 COMBIVERT F5-A, -E, -H © KEB, 2012-10
Parameter
Parameter Addr. R P E Lower limit Upper limit Default Step Unit See on page
An.33 ANOUT1 gain 0A21h appl P --- -20.00 20.00 1.00 0.01 --- 7.2-11, 7.2-14, 7.2-15
An.34 ANOUT1 offset X 0A22h appl P --- -100.0 100.0 0.0 0.1 % 7.2-14, 7.2-15
An.35 ANOUT1 offset Y 0A23h appl P --- -100.0 100.0 0.0 0.1 % 7.2-14
An.36 ANOUT2 function 0A24h appl P E 0 29 6 1 --- 7.2-13, 7.12-70
An.37 ANOUT2 value 0A25h appl P --- -100.0 100.0 0.0 0.1 % 7.2-15
An.38 ANOUT2 gain 0A26h appl P --- -20.00 20.00 1.00 0.01 --- 7.2-11, 7.2-14
An.39 ANOUT2 offset X 0A27h appl P --- -100.0 100.0 0.0 0.1 % 7.2-14
An.40 ANOUT2 offset Y 0A28h appl P --- -100.0 100.0 0.0 0.1 % 7.2-14
An.41 ANOUT3 function 0A29h appl np E 0 29 12 1 --- 7.2-11, 7.2-13
An.42 ANOUT3 value 0A2Ah appl np --- -100.0 100.0 0.0 0.1 % 7.2-15
An.43 ANOUT3 gain 0A2Bh
appl np --- -20.00 20.00 1.00 0.01 --- 7.2-14
An.44 ANOUT3 offset X 0A2Ch appl np --- -100.0 100.0 0.0 0.1 % 7.2-14
An.45 ANOUT3 offset Y 0A2Dh appl np --- -100.0 100.0 0.0 0.1 % 7.2-14
An.46 ANOUT3 period 0A2Eh appl np E 1 240 1 1 s 7.2-11, 7.2-12, 7.3-19
An.47 ANOUT4 function 0A2Fh appl np E 0 29 12 1 --- 7.2-13
An.48 ANOUT4 value 0A30h appl np --- -100.0 100.0 0.0 0.1 % 7.2-15
An.49 ANOUT4 gain 0A31h appl np --- -20.00 20.00 1.00 0.01 --- 7.2-14
An.50 ANOUT4 offset X 0A32h appl np --- -100.0 100.0 0.0 0.1 % 7.2-14
An.51 ANOUT4 offset Y 0A33h appl np --- -100.0 100.0 0.0 0.1 % 7.2-14
An.52 ANOUT4 period 0A34h appl np E 1 240 1 1 s 7.2-12, 7.3-19
An.53
analog parameter setting
max. value
0A35h appl np E 0 5 0 1 --- 7.11-15, 7.15-22
An.54
an. parameter setting max.
value
0A36h
appl np E -1: off 7FFFH -1: off 1 hex 7.11-15, 7.15-22
An.55
an. para setting offset para-
meter setting max. value
0A37h appl np --- -2^31 2^31-1 0 1 --- 7.11-15, 7.15-22
An.56
an. parameter setting max.
value
0A38h appl np --- -2^31 2^31-1 0 1 --- 7.11-16, 7.12-46, 7.12-70
An.57 an. para set. set pointer 0A39h appl np E -1: act set 7 0 1 --- 7.15-23
cn. 00 PID reference source 0700h appl P --- 0 4 0 1 ---
7.15-28, 7.15-30, 7.15-31,
7.15-32
cn. 01 PID abs. reference 0701h appl P --- -400.0 400.0 0.0 0.1 %
7.15-28, 7.15-30,
7.15-31, 7.15-32
cn. 02 PID act. value src. 0702h appl P --- 0 7 0 1 ---
7.15-29, 7.15-30, 7.15-31,
7.15-32
cn. 03 PID abs. act. value 0703h appl np --- -400.0 400.0 0.0 0.1 % 7.15-29
cn. 04 PID kp 0704h appl P --- 0.00 250.00 0.00 0.01 ---
7.15-22, 7.15-26, 7.15-30,
7.15-31, 7.15-32
cn. 05 PID ki 0705h appl P --- 0.000 30.000 0.000 0.001 --- 7.15-26
cn. 06 PID kd 0706h appl P --- 0.00 250.00 0.00 0.01
--- 7.15-26
cn. 07 PID pos. limit 0707h appl P --- -400.0 400.0 400.0 0.1 % 7.15-26, 7.15-30, 7.15-31
cn. 08 PID neg. limit 0708h appl P --- -400.0 400.0 -400.0 0.1 % 7.15-26, 7.15-30, 7.15-31
cn. 09 PID fading time 0709h appl P --- -0.01: freq 300.00 0.00 0.01 s 7.15-26
cn.10 PID reset condition 070Ah appl P --- 0 2 0 1 ---
7.15-26, 7.15-27, 7.15-30,
7.15-31, 7.15-32
cn.11 PID reset inp. sel. 070Bh appl np E 0 4095 0 1 --- 7.3-10, 7.15-26, 7.15-27
cn.12 I reset inp. sel. 070Ch appl np E 0 4095 0 1 --- 7.3-10, 7.15-26, 7.15-28
cn.13 fade in reset inp. sel. 070Dh appl np E 0 4095 0 1 ---
7.3-10, 7.15-26, 7.15-27,
7.15-28
cs.00 speed control cong. (servo) 0F00h appl P E 4 6 4 1 ---
5.1 - 3,6.2 - 4,6.2 - 6,6.2 - 9,6
.2 - 13,7.5 - 9,7.5 - 10,7.5 - 1
1,7.5 - 12,7.5 - 28,7.6 - 4,7.6
- 8,7.9 - 4,7.9 - 5,7.12 - 26,7.
12 - 79,7.13 - 13,7.13 - 24,7
.15 - 3,7.15 - 26,7.15 - 27,7.
15 - 32
cs.00
speed control cong. (Gene-
ral, Multi)
0F00h appl P E 0 127 0 1 ---
cS.01 act. source (Multi) 0F01h appl P E 0 6 0 1 ---
5.1 - 3,6.2 - 6,6.2 - 9,6.2 - 13,
6.2 - 17,6.2 - 19,7.1 - 6,7.5 -
9,7.5 - 10,7.5 - 14,7.5 - 28,7.
6 - 4,7.6 - 8,7.12 - 18,7.12 - 2
6,7.12 - 30,7.12 - 31,7.12 - 3
3,7.12 - 34,7.12 - 79,7.13 - 3
4,7.15 - 3
cS.01 act. source (Servo) 0F01h appl P E 0 5 0 1 ---
cS.01 act. source (General) 0F01h appl P E 0 6 2 1 ---
cS. 03 slipcomp. regen. gain (vvc) 0F03h appl P --- 0.50 2.50 1.00 0.01 --- 7.5-10, 7.5-11
cS.04 speed control limit (vvc) 0F04h appl P --- n * 0 n * 4000 n * 750
n *
0.125
rpm
5.1-4, 7.5-9, 7.5-10, 7.15-
32
cS. 05 KP/KI speed mode 0F05h appl P E 0 3 0 1 --- 7.7.4
further on next side
