KEB COMBIVERT F5-H User Manual

Start-up
© KEB, 2012-10 COMBIVERT F5-A, -E, -H Page 6.2 - 5
6
5. Input of the motor data
Values dr.00 to dr.05 must be taken from the motor name plate.
The value for dr.06 can be identied automatically (see point
6).
⇒ dr.00 DASM rated current
⇒ dr.01 DASM rated speed
⇒ dr.02 DASM rated voltage
⇒ dr.04 DASM cos phi
⇒ dr.05 DASM rated frequency
⇒ dr.06 DASM stator resistance
6. Measurement of the stator resistance
The stator resistance dr.06 can be determined automatically
by the KEB COMBIVERT.
Inverter must be in status „70: standstill (modulation off)“. Start
measurement with the input of
⇒ dr.06 = 250000: on
start
Open control release (X2A.16) after measurement
7. Calculation of motor-dependent data
Activation of SMM, as well as the adaption of the v/f characte-
ristic is made by the input of:
⇒ Fr.10 load motor-dep. parameter = 3
8. Adjust speed controller
The speed controller must be adapted to the application via
cS.06 and cS.09.
9.
Enterapplicationspecicdata
e.g. limit values (speed limits, torque limits etc.),
acceleration- / deceleration ramps,
function of the digital in- / outputs,
Type of speed setpoint setting etc.
Proper data for the adaption of the in-
verter to the respective application can
be nd in the corresponding chapters.
10. Test run
Test run, in order to check whether the drive runs stable in all
speed ranges and under all load conditions and if a sufcient
safety distance to the current- and load limits is available etc.
