KEB COMBIVERT F5-H User Manual

Start-up
© KEB, 2012-10 COMBIVERT F5-A, -E, -H Page 6.2 - 17
6
6. Input of the motor rating plate data
⇒ dr.23 DSM rated current
⇒ dr.24 DSM rated speed
⇒ dr.25 DSM rated frequency
⇒ dr.27 DSM rated torque
⇒ dr.28 DSM curr. f. zero speed
Note: If dr.28 is not indicated, the appro-
ximation value of dr.23 (rated current) can
be used.
Stator resistance and inductance must be
preset as phase-phase values (RUV. LUV)
and the EMC must be preset as peak value
of the phase-phase voltage (√2 x UUV).
The values can be taken from a data sheet
OR they can be automatically identied.
Identication: see step 10.
7. Input of equivalent circuit data
- dr.30 DSM winding resistance
- dr.31 DSM winding inductanc
- dr.26 DSM EMC [Vpk*1000RPM]
8. Calculation of motor-dependent data
⇒ Fr.10 load motor-dep. parameter = 2: act. DC link
voltage
9. Adjust system position
-Checking the direction of rotation. ru.09 must display a
positive speed at manual forward direction of rotation.
-Motor shaft must be mandatory free-wheeling (no-load
operation).
⇒ Ec.02 system position 1 = 2206
-close control release (X2A.16)
⇒ After successful measurement ru00 = 127 : cddr/ „drive
data calculated“ is displayed.
-open control release again (X2A.16)
See chapter 7.6. for all data of the system
position trimming.
10.
ifnecessaryidenticationoftheequivalentcircuitdata
⇒ dr.48 motor identication = 7: Auto identication wit-
hout EMC
-close control release (X2A.16)
⇒ After successful identication ru00 = 127 : cddr/ „drive
data calculated“ is displayed.
-open control release again (X2A.16)
Note:
The EMC is not measured by identication,
but it is calculated from the rated data.
Read chapter 7.6 for further data of the
identication
