KEB COMBIVERT F5-H User Manual

Page 7.1 - 10 COMBIVERT F5-A, -E, -H © KEB, 2012-10
Operating and appliance data
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
ru.30 AN 1 / post amplier
display
021Eh RO - - -400 400 0.1 % -
This parameter shows the value of the analog signal AN2 in percent after passing the characteristic amplier.
The range of indication is limited to ±400 % (also see chapt. 7.2 „Analog inputs“).
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
ru.31 AN 3 / pre amplier
display
021Eh RO - - -100 100 0.1 % -
This parameter shows the value of the analog signal on the optionally analog input AN3 before signal ampli-
cation in percent. The indicated value of 0...±100 % corresponds depending on An.10: 0...±10 V (see also
chapt. 7.2 „Analog inputs“).
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
ru.32 AN 3 / post amplier
display
021Fh RO - - -400 400 0.1 % -
This parameter shows the value of the analog signal on the optionally analog input AN3 after signal ampli-
cation in percent. The range of indication is limited to ±400 % (also see chapt. 7.2 „Analog inputs“).
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
ru.33 ANOUT 1 / pre amplier
display
0221h RO - - -400 400 0.1 % -
This parameter shows the value of the analog signal ANOUT1 in percent before passing the characteristic
amplier (also see 7.2 „Analog outputs“).
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
ru.34 ANOUT 1 / post ampli-
er display
0222h RO - - -115 115 0.1 % -
This parameter shows the value of the signal given out on analog output ANOUT1 (terminal X2A.5) in percent.
A value of 0...±100 % correponds to an output signal of 0...±11,5 V (also see chapt. 7.2 „Analog outputs“).
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
ru.35 ANOUT 1 / pre amplier
display
0223h RO - - -400 400 0.1 % -
This parameter shows the value of the analog signal ANOUT1 in percent before passing the characteristic
amplier (also see 7.2 „Analog outputs“).
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
ru.36 ANOUT 1 / post ampli-
er display
0224h RO - - -115 115 0.1 % -
This parameter shows the value of the signal given out on analog output ANOUT2 (terminal X2A.6) in percent.
A value of 0...±100 % correponds to an output signal of 0...±11,5 V (also see chapt. 7.2 „Analog outputs“).
