Operating and appliance data

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.53 AUX display 0235h RO - - -400.0 400.0 0.1 % -

The AUX input is adjusted with An.30. This parameter shows the value of the analog signal AUX in percent.

The display range is limited to ±400 % (also see chapt. 6.2 „Analog inputs“).

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.54 actual position 0236h RO - - -2147483647 2147483647 1 Inc -

ru.54 displays the absolute actual position in increments.

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.55 set position 0237h RO - - -2147483647 2147483647 1 Inc -

ru.55 displays the absolute set position in increments.

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.58 angle difference 023Ah RO - - -2147483647 2147483647 1 Inc -

This parameter displays the actual angular difference between set and actual position.

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.59 rotor adaption factor 023Bh RO - - 0 100 1 % -

This parameter displays the actual factor of the rotor adaption.

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.60 act. position index 023Ch RO - - 0 255 1 - -

This parameter displays the actual position index of the position prole.

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.61 target position 023Dh RO - - -2147483647 2147483647 1 Inc -

This parameter displays the target position of the actual position index.

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.63 prole speed 023Fh RO - - -4000 4000 0.125 rpm -

This parameter displays the speed of the actual position index.

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.68 Rated DC voltage 0244h RO - - 0 1000 1 V -

This parameter displays the rated DC link voltage automatically determined by the inverter. The value is

measured at switch-on.

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.69 Distance ref.- zeropoint 0245h RO - - -2147483647 2147483647 1 Inc -

This parameter displays the distance to the zeropoint after relieve the reference switch.
