KEB COMBIVERT F5-H User Manual

Page 7.1 - 24 COMBIVERT F5-A, -E, -H © KEB, 2012-10
Operating and appliance data
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
SY.57 Watchdog time address 0039h cp-
ro
np – -2 -1 1 hex -2
Parameter Addr. R PG E Min. value Max.
value
Res. [?] Default
SY.58 Proc. read data 5 de-
nition
003Ah * - + -1 7FFFh 1 hex -1
SY.60 Proc. read data 6 de-
nition
003Ch * - + -1 7FFFh 1 hex -1
SY.62 Proc. read data 7 de-
nition
003Eh * - + -1 7FFFh 1 hex -1
SY.64 Proc. read data 8 de-
nition
0040h * - + -1 7FFFh 1 hex -1
* rw via bus; r via keyboard
Parameter Addr. R PG E Min. value Max.
value
Res. [?] Default
SY.59 Proc. read data 5 set 003Bh * - + 1 128 1 hex 1
SY.61 Proc. read data 6 set 003Dh * - + 1 128 1 hex 1
SY.63 Proc. read data 7 set 003Fh * - + 1 128 1 hex 1
SY.65 Proc. read data 8 set 0041h * - + 1 128 1 hex 1
* rw via bus; r via keyboard
Parameter Addr. R PG E Min. value Max. value Res. [?] Def-
ault
SY.77 Control word S4 004Dh RW - + 0 7FFFFh 1 hex 0
A compatible control or status word has been introduced in order to permit an easier replace of old S4 appli-
cations with F5.
Mapping of the control word of the S4 30F software
Bit -No. Function
0 Input I4, manual drive to higher values
1 Input I2, manual drive to smaller values
2 Start positioning
3 Input IA
4 Modulation release AND operation with ST
5 Input IB
6 Input IC
7 Input ID
8 Abort posi
9 Start approach to reference point
10 Output OUT3
11 free
12 0 = servo axis, 1 = traction axis
13…15 free
